3-32(No.YA665<Rev.001>)
SW P.W. BOARD ASS'Y (SFL-7221A-H8)
R641 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R642 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R643 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R644 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R650 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R651 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R655 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R659 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R660 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R661 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R662 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R663 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R664 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R665 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R666 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R667 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R668 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R669 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R670 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R671 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R755 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R756 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R757 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R758 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R759 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R760 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R761 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R763 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R764 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R765 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R768 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R769 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R770 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R777 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R778 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R779 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R780 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R783 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R786 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R787 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R902 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
R982 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
R3006 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3007 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3008 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3009 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R3010 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3011 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3014 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3015 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3016 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3019 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3020 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3021 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3024 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3025 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3026 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3504 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3505 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3506 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3508 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3511 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R3512 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3514 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3515 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3516 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3517 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3546 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R3547 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R6106 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R6107 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R6108 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R6109 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R6113 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6115 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6117 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6118 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R6119 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R6120 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R6124 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R6127 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R6134 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6141 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R6142 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R6143 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
L101 NQL79GM-100X COIL 10uH M
L601 NQLE42M-100X MM1689OR 10uH M
L605 NQLE42M-100X MM1689OR 10uH M
 Ref No. Part No. Part Name Description Local
L606 NQLE42M-100X MM1689OR 10uH M
L607 NQLE42M-100X MM1689OR 10uH M
L608 NQLE42M-100X MM1689OR 10uH M
L609 NQLE42M-100X MM1689OR 10uH M
L902 NQL52EM-220X COIL 22uH M
L903 NQR0562-010X CHOKE COIL
L3002 NQL79GM-100X COIL 10uH M
L3003 NQL79GM-220X COIL 22uH M
L3502 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3503 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3504 NQL79GM-4R7X COIL 4.7uH M
L3506 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3507 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L6101 NQLF3EM-330X COIL 33uH M
L6102 NQLF3EM-330X COIL 33uH M
L6103 NQLF3EM-330X COIL 33uH M
L6104 NQLF3EM-330X COIL 33uH M
CN001 QGF0508C2-50W CONNECTOR FFC/FPC (1-50)
CN002 QGF0508C2-40W CONNECTOR FFC/FPC (1-40)
CN00H QGB1231L1-23 CONNECTOR B-B (1-23)
J401 QNZ0726-001 AV JACK VIDEO-1(S/V/L/R)
J402 QNN0650-001 PIN JACK
VIDEO-1(COMPONENT)
J403 QNZ0726-001 AV JACK VIDEO-2(S/V/L/R)
J405 QNN0651-001 PIN JACK VIDEO-3(V/L/R)
J406 QNN0650-001 PIN JACK
VIDEO-3(COMPONENT)
J407 QNN0652-001 PIN JACK AUDIO IN(HDMI-1)
J408 QNZ0726-001 AV JACK AUDIO OUT(S/V/L/R)
J410 QNZ0973-001 D CONNECTOR PC IN
K101 NQR0389-003X FERRITE BEADS
K102 NQR0389-003X FERRITE BEADS
K103 NQR0389-003X FERRITE BEADS
K104 NQR0389-003X FERRITE BEADS
K105 NQR0389-003X FERRITE BEADS
K106 NQR0389-003X FERRITE BEADS
K107 NQR0389-003X FERRITE BEADS
K108 NQR0389-003X FERRITE BEADS
K601 NQR0499-002X FERRITE BEADS
K3501 NQR0389-003X FERRITE BEADS
K3502 NQR0389-003X FERRITE BEADS
K6101 NQR0499-002X FERRITE BEADS
K6102 NQR0499-002X FERRITE BEADS
K6103 NQR0499-002X FERRITE BEADS
K6104 NQR0499-002X FERRITE BEADS
K6601 NQR0499-002X FERRITE BEADS
LC3501 NQR0436-001X EMI FILTER
TU3001 QAU0390-001 TUNER
X601 NAX0932-001X CRYSTAL 12.288MHz
X3501 QAX0773-001Z CRYSTAL 18.432000MHz
 Ref No. Part No. Part Name Description Local
D7011 UDZW6.2B-X Z DIODE
C7011 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7012 NCB31CK-104X C CAPACITOR 0.1uF 16V K
R7011 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R7012 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R7013 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7014 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7015 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R7016 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R7701 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R7702 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R7703 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R7704 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R7707 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7708 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7710 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7711 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
J7001 QNS0097-002 3.5 JACK HEADPHONE
S7701 QSW1121-001Z PUSH SWITCH CH-
S7702 QSW1121-001Z PUSH SWITCH CH+
S7703 QSW1121-001Z PUSH SWITCH MENU/OK
S7704 QSW1121-001Z PUSH SWITCH TV/AV
S7705 QSW1121-001Z PUSH SWITCH VOL+
S7706 QSW1121-001Z PUSH SWITCH VOL-
S7707 QSW1121-001Z PUSH SWITCH POWER
 Ref No. Part No. Part Name Description Local
