(No.YA665<Rev.001>)3-35
DC-DC P.W. BOARD ASS'Y (SFL-91A1A-H8)
DIGITAL P.W. BOARD ASS'Y (SFL0D403A-H8)
 Ref No. Part No. Part Name Description Local
IC9401 S393-X IC
IC9701 AL1042-X IC
Q9401 2SC1623A/5-6/-X TRANSISTOR
Q9601 2SC1623A/5-6/-X TRANSISTOR
Q9602 UN2213-X DIGI TRANSISTOR
Q9701 RSS090N03-X POWER MOS FET
Q9702 RSS090N03-X POWER MOS FET
Q9703 2SC1623A/5-6/-X TRANSISTOR
D9401 UDZW9.1B-X Z DIODE
D9402 1SS355W-X DIODE
D9403 1SS355W-X DIODE
D9604 PTZ16B-X Z DIODE
D9605 1SS355W-X DIODE
D9606 1SS355W-X DIODE
D9701 1SS357-X DIODE
D9702 EC30HA04-X SB DIODE
D9703 PTZ6.8B-X Z DIODE
D9704 1SS355W-X DIODE
D9705 UDZW3.0B-X Z DIODE
D9706 1SS355W-X DIODE
C9401 NEHM1HM-105X E CAPACITOR 1uF 50V M
C9402 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9403 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9404 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9451 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9452 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9453 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9454 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9455 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9456 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9701 NCB11AK-106X C CAPACITOR 10uF 10V K
C9702 NCJ11HK-105X-U C CAPACITOR 1uF 50V K
C9703 QEZ0849-128 E CAPACITOR 1200uF
C9704 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9705 NCB21EK-105X C CAPACITOR 1uF 25V K
C9706 NDC31HJ-101X C CAPACITOR 100pF 50V J
C9707 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C9709 NEX60JM-227X E CAPACITOR 220uF 6.3V M
C9710 NEX60JM-227X E CAPACITOR 220uF 6.3V M
C9711 NEHM1HM-105X E CAPACITOR 1uF 50V M
C9712 NEZ0038-227X E CAPACITOR 220uF
C9714 NCJ11HK-105X-U C CAPACITOR 1uF 50V K
C9715 NCB11HK-104X C CAPACITOR 0.1uF 50V K
C9721 NDC31HJ-152X C CAPACITOR 1500pF 50V J
C9723 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9724 NDC31HJ-152X C CAPACITOR 1500pF 50V J
C9981 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9982 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9983 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9984 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9985 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9986 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9987 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9988 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9989 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9991 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9992 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9993 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9998 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R9401 NRS12BJ-332W MG RESISTOR 3.3k
Ω 1/2W J
R9402 NRSA63D-472X MG RESISTOR 4.7k
Ω 1/16W D
R9403 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R9404 NRSA63D-472X MG RESISTOR 4.7k
Ω 1/16W D
R9405 NRSA63D-273X MG RESISTOR 27k
Ω 1/16W D
R9406 NRSA63D-472X MG RESISTOR 4.7k
Ω 1/16W D
R9407 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R9408 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R9409 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R9611 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R9612 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R9613 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R9614 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R9701 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
R9702 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
R9704 NRZ0096-R010X MP RESISTOR 0.01
Ω
R9706 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R9707 NRSA63D-183X MG RESISTOR 18k
Ω 1/16W D
R9708 NRSA63J-824X MG RESISTOR 820k
Ω 1/16W J
R9709 NRSA63D-332X MG RESISTOR 3.3k
Ω 1/16W D
R9710 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R9711 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R9712 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R9713 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R9719 NRS181J-100X MG RESISTOR 10 Ω 1/8W J
R9720 NRSA63D-154X MG RESISTOR 150k
Ω 1/16W D
R9723 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R9750 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L9702 NQLB1EN-7R4X COIL 7.4uH N
L9703 NQR0562-002X CHOKE COIL
L9902 NQLE42M-470X SNDUCTOR 47uH M
CN00A WJK0249-001A-E E-SI C WIRE C-B
CN00H QGB1231M1-23 CONNECTOR B-B (1-23)
K9701 NQR0413-001X FERRITE BEADS
K9702 NQR0413-001X FERRITE BEADS
 Ref No. Part No. Part Name Description Local
IC5001 JCC5070 IC
IC5002 EDD1232ABBH-5C IC
IC5003 EDD1232ABBH-5C IC
IC5503 BU7986KUT IC
IC6001 JCC5068 IC
IC6002 74LVC1G08GW-X IC
IC6004 ICS574MLF-X IC
IC6101 EDD1232AAFA-6B IC
IC6102 AIC1384PSH-X IC
IC6250 UPC5702GS-027-X IC
IC6251 S-1170B33UC-W IC
IC6301 TC7SET08F-X IC
IC6302 TC7SET08F-X IC
IC6303 TC7SH86FU-X IC
IC6503 BU7986KUT IC
IC6509 TC7SET08F-X IC
IC6510 MM3143DN-X IC
IC6724 S-80928CLNB-G-W IC
IC6901 R1141Q331B-X IC
IC7033 74HC4094PW-X IC
IC7036 ADC081S021CIS-X IC
IC7201 39VF80A7IEKLJ09 IC(MICRO C ROM)
IC7203 M12L16161A7T11U IC
IC7204 S-80928CLNB-G-W IC
IC7301 SDA6000-B12 IC
IC7302 SA16D90-52GZ IC(MICRO C ROM) (SERVICE)
IC7303 K4S641632K-UC75 IC
IC7304 TC74HC4053AFT-X IC(DIGITAL)
IC7305 MM1689CH-X IC
IC7306 S-80928CLNB-G-W IC
IC7602 ATF32-52GZ79BA IC (SERVICE)
IC7606 MM1671XN-X IC
IC9000 THV1021-X IC
IC9101 MM1662FT-X IC
IC9102 MM1662FT-X IC
IC9251 MM1701CH-X IC
IC9301 MM1701CH-X IC
Q6202 2SA1530A/QR/-X TRANSISTOR
Q6203 RT1A3906-X TRANSISTOR
Q6204 RT1A3906-X TRANSISTOR
Q6205 RT1A3906-X TRANSISTOR
Q6206 RT1A3906-X TRANSISTOR
Q6207 2SC5477-X TRANSISTOR
Q6208 2SC5477-X TRANSISTOR
Q6209 2SC5477-X TRANSISTOR
Q6210 2SC5477-X TRANSISTOR
Q6211 2SC5477-X TRANSISTOR
Q6212 2SC5477-X TRANSISTOR
Q6213 2SC5477-X TRANSISTOR
Q6214 2SC5477-X TRANSISTOR
Q6250 2SC3928A/QR/-X TRANSISTOR
Q6251 2SC3928A/QR/-X TRANSISTOR
Q6301 2SA1530A/QR/-X TRANSISTOR
Q6302 HN1C01F/Y/-X PAIR TRANSISTOR
Q6303 2SA1530A/QR/-X TRANSISTOR
Q6304 HN1C01F/Y/-X PAIR TRANSISTOR
Q6501 2SC3928A/QR/-X TRANSISTOR
Q6505 INK0001AM1-X MOS FET
Q6506 INK0001AM1-X MOS FET
Q7030 RT1N441C-X TRANSISTOR
Q7032 RT1P441C-X DIGI TRANSISTOR
Q7033 RT1P441C-X DIGI TRANSISTOR
Q7034 RT1P441C-X DIGI TRANSISTOR
Q7035 RT1P441C-X DIGI TRANSISTOR
Q7041 RT1N441C-X TRANSISTOR
Q7301 UN2213-X DIGI TRANSISTOR
 Ref No. Part No. Part Name Description Local
