JVC LT-52GZ79 User Manual

3-4(No.YA665<Rev.001>)
EXPLODED VIEW PARTS LIST -1
 Ref.No. Part No. Part Name Description Local
LV1 WJW0097-001A-E DIGITAL(LVDS) CABLE
LV2 WJW0098-001A-E DIGITAL(LVDS) CABLE
 1 LC13360-002A-0K REAR COVER
 2 LC13345-003A-0K FRONT PANEL
5 LC42777-005A-C SPEAKER
6 LC42777-002A-C SPEAKER
 7 QMPRB50-170-Q1 POWER CORD 1.7m BLACK LT-52GZ79,LT-52GZ79E
 7 QMPRA90-165-Q1 POWER CORD 1.65m BLACK LT-52GZ79BA
 7 QMPN370-170-JC POWER CORD 1.7m BLACK LT-52GZ79S
 8 LC13337-002B-H TERMINAL BASE
9 LC13348-001C-C MAIN BASE
10 LC22577-001A-C SIDE BRACKET (x2)
11 LC33981-002A-H BACK BRACKET (x2)
14 LC13350-001B-C STAND SUPPORT
16 LC13349-001A-H STAND BASE UNIT
18 LC12497-020A-H SHIELD TERMINAL
 20 LC34028-002A-H POWER CORD COVER
 21 LC33980-001A-H CONTROL KNOB
22 LC22423-005A-H KNOB BASE
23 LC33936-001A-H CORD CLAMP
24 LC34239-001A-C TOP BRACKET (x2)
 26 LC12507-006B-0K TUNER BASE
27 LC12496-001F-H SHIELD COVER
28 LC12495-002F-H SHIELD BASE
32 LC34030-001C-H ILLUMI LENS
50 LC42784-002A SCREW (x10)
51 QYSBSFG3010MA TAP SCREW M3 x 10mm(x11)
52 LC41424-002A GDCP WARNING
53 QYSBSFG3010MA TAP SCREW M3 x 10mm
54 QYSBSFG3010MA TAP SCREW M3 x 10mm
55 QYSPSPD5016MA SCREW M5 x 16mm(x4)
56 QYSPSPD5030ZA SCREW M5 x 30mm(x6)
57 LC42152-003A COOLING SHEET
58 CM34837-008-H STICK SHEET
59 LC42991-003A COOLING SHEET
60 WJJ0920-002A-E WIRE DIGITAL CN0DC - DC-DC CN0DC
61 WJJ0846-002A-E WIRE DIGITAL CN001W - POWER CN00W
62 QUQR05-5009AB-E FFC WIRE DIGITAL CN001 - ANALOG CN001
63 QUQR05-4009AB-E FFC WIRE DIGITAL CN002 - ANALOG CN002
64 QYSPSP3004ZA SCREW M3 x 4mm(x3)
 65 LC43110-001A SERVICE SHEET
66 QZW0338-001 EDGING
67 WJJ0843-001A-E WIRE POWER CN00F-ANALOG CN10F
68 WJJ0844-001B-E WIRE POWER CN00P - LCD PANEL UNIT
69 WJJ0921-001A-E WIRE POWER CN00Q - LCD PANEL UNIT
70 QQR0491-001 FERRITE CORE LT-52GZ79,LT-52GZ79E,LT-52GZ79S
71 QZW0156-002 WIRE CLAMP
72 LC13464-001A-C STAND BRACKET
73 QZW0375-001 EDGING
74 LC34128-010A-C SOFT GASKET LT-52GZ79,LT-52GZ79E,LT-52GZ79S
75 QNB0036-001 CONN ACCESSORY (x2)
76 QQR0490-001 NOISE FILTER LT-52GZ79,LT-52GZ79E,LT-52GZ79S
77 LC42784-002A SCREW (x3)
78 QYSBSF3010MA TAP SCREW M3 x 10mm(x7)
80 WJZ0282-010A-E WIRE
SW CN100R - ANALOG CN00R/CN00U - LED CN100U
81 LC22575-001A-0K CONTROL BASE
82 LC40226-005A-H SPACER (x6)
83 LC41458-002A TAPPING SCREW (x6)
84 QZW0156-002 WIRE CLAMP
85 LC33978-007B-H INDICATE WINDOW
86 LC13523-003A-H FRONT WINDOW
 200 SFL-90A5A-H2 POWER PWB LT-52GZ79,LT-52GZ79S
 200 SFL-90A5A-H8 POWER PWB LT-52GZ79BA
 200 SFL-90A6A-H2 POWER PWB LT-52GZ79E
 201 SFL-1237A-H2 ANALOG PWB LT-52GZ79,LT-52GZ79E,LT-52GZ79S
 201 SFL-1237A-H8 ANALOG PWB LT-52GZ79BA
 202 SFL0D403A-H2 DIGITAL PWB LT-52GZ79,LT-52GZ79E
 202 SFL0D403A-H8 DIGITAL PWB LT-52GZ79BA
 202 SFL0D404A-H2 DIGITAL PWB LT-52GZ79S
 203 SFL-7221A-H2 SW PWB LT-52GZ79,LT-52GZ79E,LT-52GZ79S
 203 SFL-7221A-H8 SW PWB LT-52GZ79BA
 204 SFL-8728A-H2 LED PWB LT-52GZ79,LT-52GZ79E,LT-52GZ79S
 204 SFL-8728A-H8 LED PWB LT-52GZ79BA
 205 SFL-91A1A-H2 DC-DC PWB LT-52GZ79,LT-52GZ79E,LT-52GZ79S
 205 SFL-91A1A-H8 DC-DC PWB LT-52GZ79BA
