(No.YA665<Rev.001>)3-21
DC-DC P.W. BOARD ASS'Y (SFL-91A1A-H2)
REFER TO PARTS LIST IN PAGE 3-13 FOR THIS P.W. BOARD.
DIGITAL P.W. BOARD ASS'Y (SFL0D403A-H2)
REFER TO PARTS LIST IN PAGE 3-13 FOR THIS P.W. BOARD.
R9002 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R9003 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9004 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R9005 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9007 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R9010 QRZ9058-8R2 C RESISTOR 8.2
Ω
R9205 NRS12BJ-224W MG RESISTOR 220k
Ω
1/2W J
R9206 NRS12BJ-101W MG RESISTOR 100
Ω
1/2W J
R9207 NRSA63J-394X MG RESISTOR 390k
Ω
1/16W J
R9208 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R9209 QRZ9046-825Z C RESISTOR 8.2M
Ω
1/2W K
R9210 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R9211 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R9212 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9213 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9214 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R9215 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9216 NRS12BJ-102W MG RESISTOR 1k
Ω
1/2W J
R9221 QRE121J-220Y C RESISTOR 22
Ω
1/2W J
R9501 QRM059J-R15 MP RESISTOR 0.15
Ω
5W J
R9502 QRM059J-R15 MP RESISTOR 0.15
Ω
5W J
R9503 NRS181J-474X MG RESISTOR 470k
Ω
1/8W J
R9504 NRS181J-474X MG RESISTOR 470k
Ω
1/8W J
R9505 NRS181J-334X MG RESISTOR 330k
Ω
1/8W J
R9506 NRSA63D-912X MG RESISTOR 9.1k
Ω
1/16W D
R9507 NRS12BJ-223W MG RESISTOR 22k
Ω
1/2W J
R9508 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R9509 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R9510 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R9511 NRS181J-824X MG RESISTOR 820k
Ω
1/8W J
R9512 NRS181J-824X MG RESISTOR 820k
Ω
1/8W J
R9513 NRS181J-824X MG RESISTOR 820k
Ω
1/8W J
R9514 NRSA63D-183X MG RESISTOR 18k
Ω
1/16W D
R9515 NRSA63D-224X MG RESISTOR 220k
Ω
1/16W D
R9516 NRS181J-334X MG RESISTOR 330k
Ω
1/8W J
R9517 NRS181J-334X MG RESISTOR 330k
Ω
1/8W J
R9518 NRS181J-394X MG RESISTOR 390k
Ω
1/8W J
R9519 NRS181J-474X MG RESISTOR 470k
Ω
1/8W J
R9520 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
R9521 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9522 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R9523 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9524 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9525 NRSA63J-824X MG RESISTOR 820k
Ω
1/16W J
R9526 NRS12BJ-102W MG RESISTOR 1k
Ω
1/2W J
R9527 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9528 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R9529 NRS12BJ-101W MG RESISTOR 100
Ω
1/2W J
R9530 NRS12BJ-220W MG RESISTOR 22
Ω
1/2W J
R9532 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9533 NRSA02J-562X MG RESISTOR 5.6k
Ω
1/10W J
R9534 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9540 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R9551 QRZ9046-105Z C RESISTOR 1M
Ω
1/2W K
R9552 NRS12BJ-470W MG RESISTOR 47
Ω
1/2W J
R9553 NRS181J-223X MG RESISTOR 22k
Ω
1/8W J
R9555 NRS12BJ-220W MG RESISTOR 22
Ω
1/2W J
R9556 NRS181J-104X MG RESISTOR 100k
Ω
1/8W J
R9557 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R9558 NRS181J-103X MG RESISTOR 10k
Ω
1/8W J
R9559 NRSA02J-223X MG RESISTOR 22k
Ω
1/10W J
R9560 NRS181J-183X MG RESISTOR 18k
Ω
1/8W J
R9561 NRS181J-103X MG RESISTOR 10k
Ω
1/8W J
R9564 NRS181J-683X MG RESISTOR 68k
Ω
1/8W J
R9565 NRS12BJ-821W MG RESISTOR 820
Ω
1/2W J
R9568 NRZ0096-R010X MP RESISTOR 0.01
Ω
R9569 NRZ0096-R010X MP RESISTOR 0.01
Ω
R9572 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9573 NRSA02J-562X MG RESISTOR 5.6k
Ω
1/10W J
R9574 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
R9576 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9577 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9578 NRS12BJ-151W MG RESISTOR 150
Ω
1/2W J
R9580 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9603 NRS12BJ-222W MG RESISTOR 2.2k
Ω
1/2W J
R9604 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9605 NRSA02J-103X MG RESISTOR 10k
Ω
1/10W J
R9606 NRSA63D-273X MG RESISTOR 27k
Ω
1/16W D
R9607 NRSA63D-682X MG RESISTOR 6.8k
Ω
1/16W D
R9608 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9609 NRSA63D-392X MG RESISTOR 3.9k
Ω
1/16W D
R9621 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R9625 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R9631 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R9641 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R9701 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9703 NRSA63D-102X MG RESISTOR 1k
Ω
1/16W D
R9704 NRSA63D-683X MG RESISTOR 68k
Ω
1/16W D
R9706 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
Ref No. Part No. Part Name Description Local
R9708 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R9709 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9802 QRL02EJ-473X OMF RESISTOR 47k
Ω
2W J
R9803 QRE121J-564Y C RESISTOR 560k
Ω
1/2W J
R9804 QRL03EJ-220X OMF RESISTOR 22
Ω
3W J
R9805 QRE121J-224Y C RESISTOR 220k
Ω
1/2W J
R9806 QRE121J-224Y C RESISTOR 220k
Ω
1/2W J
R9807 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9808 QRE121J-151Y C RESISTOR 150
Ω
1/2W J
R9809 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R9810 QRE121J-102Y C RESISTOR 1k
Ω
1/2W J
R9811 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9812 QRT01EJ-R39X MF RESISTOR 0.39
Ω
1W J
R9813 QRT01EJ-R82X MF RESISTOR 0.82
Ω
1W J
R9814 QRK126J-221X UNF C RESISTOR 220
Ω
1/2W J
R9901 QRL01EJ-821X OMF RESISTOR 820
Ω
1W J
R9902 QRL02EJ-152X OMF RESISTOR 1.5k
Ω
2W J
R9903 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9904 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9905 NRSA63D-183X MG RESISTOR 18k
Ω
1/16W D
R9906 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R9907 NRSA63D-332X MG RESISTOR 3.3k
Ω
1/16W D
L9201 QQL26AM-5R6Z CHOKE COIL 5.6uH M
L9501 QQR1789-001 CHOKE COIL
L9502 QQR1513-001 CHOKE COIL
L9651 QQL244J-101Z PEAKING COIL 100uH J
L9701 QQL26AK-100Z CHOKE COIL 10uH K
L9702 QQR1432-001 CHOKE COIL
L9703 QQL26AK-100Z CHOKE COIL 10uH K
L9753 QQL26AM-4R7Z COIL 4.7uH M
L9801 QQR1130-003 CHOKE COIL
L9903 QQL26AK-100Z CHOKE COIL 10uH K
T9201 QQS0381-001 SW TRANSF
T9501 QQS0406-002 SW TRANSF
T9801 QQS0380-001 SW TRANSF
CP9201 QMFZ052-2R0Z-E FUSE 2A
CP9501 QMFZ043-5R0Z-J1 FUSE 5A AC250V
CP9601 ICP-N70-T IC PROTECTOR 2.5A
CP9801 QMFZ043-5R0Z-J1 FUSE 5A AC250V
CP9901 QMFZ034-5R0Z-J1 FUSE 5A 125V
CP9902 ICP-N50-T IC PROTECTOR 2.0A
F9001 QMF5AD2-6R3-J1 FUSE 6.3A AC250V
K9201 QQR0621-002Z FERRITE BEADS
K9202 QQR0621-002Z FERRITE BEADS
K9502 QQR0621-002Z FERRITE BEADS
K9503 QQR0621-002Z FERRITE BEADS
K9607 QQR0621-002Z FERRITE BEADS
K9608 QQR0621-002Z FERRITE BEADS
K9609 QQR0621-002Z FERRITE BEADS
K9610 QQR0621-002Z FERRITE BEADS
K9751 NQR0499-002X FERRITE BEADS
LF9001 QQR1654-001 LINE FILTER
LF9002 QQR1281-005 LINE FILTER
LF9003 QQR1784-001 LINE FILTER
PC9202 PS2581AL1/QW/ PHOTO COUPLER
PC9501 PS2581AL1/QW/ PHOTO COUPLER
PC9502 PS2581AL1/QW/ PHOTO COUPLER
PC9503 PS2581AL1/QW/ PHOTO COUPLER
PC9504 PS2581AL1/QW/ PHOTO COUPLER
PC9801 PS2581AL1/QW/ PHOTO COUPLER
RY9001 QSK0162-001 RELAY
RY9002 QSK0162-001 RELAY
TH9001 QAD0174-250 P THERMISTOR 25
Ω
VA9001 QAF0028-621 VARISTOR 620V
Ref No. Part No. Part Name Description Local
