JVC LT-52GZ79 User Manual

(No.YA665<Rev.001>)3-33
LED P.W. BOARD ASS'Y (SFL-8728A-H8)
POWER P.W. BOARD ASS'Y (SFL-90A5A-H8)
 Ref No. Part No. Part Name Description Local
IC8751 S9648 PHOTO CONDUCTOR
IC8752 GP1UM261RKVF IR DETECT UNIT
Q8705 UN2110-X DIGI TRANSISTOR
Q8709 UN2212-X DIGI TRANSISTOR
Q8712 UN2212-X DIGI TRANSISTOR
Q8713 UN2212-X DIGI TRANSISTOR
D8702 SELT5E20CS/EF/T LED POWER
D8705 SELT5E20CS/EF/T LED ILLUMINATION
D8706 UDZW6.8B-X Z DIODE
D8707 UDZW6.8B-X Z DIODE
D8712 UDZW6.8B-X Z DIODE
D8713 UDZW6.8B-X Z DIODE
C8751 NEHL1EM-226X E CAPACITOR 22uF 25V M
C8752 NCJ41CM-226X-U C CAPACITOR 22uF 16V M
R8714 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R8717 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R8722 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R8723 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R8724 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R8751 NRSA63J-274X MG RESISTOR 270k
Ω 1/16W J
R8752 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R8753 NRSA63J-683X MG RESISTOR 68k
Ω 1/16W J
R8754 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R8755 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
IC9201 MIP2F30MSSCF IC
IC9501 MP2A5038-F233 IC
 IC9502 FA5500AN-W IC
IC9601 TL431/A/-T IC
IC9701 PQ1CG2032FZ IC
IC9801 STR-W6765-F5 IC
IC9901 TL431/A/-T IC
Q9001 2SC1623A/5-6/-X TRANSISTOR
Q9002 2SC1623A/5-6/-X TRANSISTOR
Q9501 2SK3522A-01 POWER MOS FET
Q9502 2SC1623A/5-6/-X TRANSISTOR
Q9503 2SC1623A/5-6/-X TRANSISTOR
Q9504 UN2213-X DIGI TRANSISTOR
Q9505 UN2212-X DIGI TRANSISTOR
Q9506 UN2212-X DIGI TRANSISTOR
Q9507 2SB1188/QR/-W TRANSISTOR
Q9508 UN2212-X DIGI TRANSISTOR
Q9551 2SC1623A/5-6/-X TRANSISTOR
Q9555 2SB1188/QR/-W TRANSISTOR
Q9556 UN2212-X DIGI TRANSISTOR
Q9557 UN2213-X DIGI TRANSISTOR
Q9558 UN2213-X DIGI TRANSISTOR
Q9602 UN2212-X DIGI TRANSISTOR
Q9603 UN2212-X DIGI TRANSISTOR
Q9604 UN2212-X DIGI TRANSISTOR
Q9701 2SC1623A/5-6/-X TRANSISTOR
Q9702 UN2213-X DIGI TRANSISTOR
 D9001 TS25P05G-C2 BRIDGE DIODE
D9002 1SS355W-X DIODE
D9003 1SS355W-X DIODE
D9005 1SS355W-X DIODE
D9006 1SS355W-X DIODE
D9203 EG01C-T2 SI DIODE
D9204 SJPX-H6-W DIODE
D9205 TL431/A/-T IC
D9206 EC21QS10-X SB DIODE
D9212 EM1A-T2 SI DIODE
D9213 EM1A-T2 SI DIODE
D9214 EM1A-T2 SI DIODE
D9215 MA8330/M/-X Z DIODE
D9216 MA8330/M/-X Z DIODE
D9218 SJPX-H6-W DIODE
D9501 YG972S6R SI DIODE
D9502 RF101L2S-X DIODE
D9503 1SS355W-X DIODE
D9504 1SS355W-X DIODE
D9505 RF101L2S-X DIODE
D9506 1SS355W-X DIODE
D9507 MA8100/M/-X Z DIODE
D9508 1SS355W-X DIODE
D9552 SD883-04-X SB DIODE
D9553 PTZ27B-X Z DIODE
D9554 PTZ27B-X Z DIODE
D9555 SD883-04-X SB DIODE
D9556 UDZW3.9B-X Z DIODE
D9561 1SS355W-X DIODE
D9601 FCHS20A08 SB DIODE
D9602 FCHS20A08 SB DIODE
D9603 FCHS20A08 SB DIODE
D9604 FCHS20A08 SB DIODE
D9653 MTZJ16B-T2 Z DIODE
D9654 MTZJ16B-T2 Z DIODE
D9702 EC30HA03L-X SB DIODE
D9801 D2SBA60 BRIDGE DIODE
D9802 FR105GT-T3 SI DIODE
D9803 SARS01-T2 FR DIODE
D9804 SARS01-T2 FR DIODE
D9805 1SS355W-X DIODE
D9806 MTZJ33B-T2 Z DIODE
D9807 FR105GT-T3 SI DIODE
D9808 FR105GT-T3 SI DIODE
D9809 1SS355W-X DIODE
D9810 1SS355W-X DIODE
D9902 FMX-G12S SI DIODE
D9903 FMX-22S SI DIODE
D9904 FR105GT-T3 SI DIODE
 C9001 QFZ9084-474 MPP CAPACITOR 0.47uF
 C9002 QFZ9084-474 MPP CAPACITOR 0.47uF
 C9003 QCZ9071-681 C CAPACITOR 680pF AC400V M
 C9004 QCZ9071-331 C CAPACITOR 330pF AC400V K
 C9006 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9007 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9008 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9009 QCZ9078-222 C CAPACITOR 2200pF AC250V M
C9012 QEHR0JM-108Z E CAPACITOR 1000uF 6.3V M
C9204 QEZ0709-106 E CAPACITOR 10uF 450V M
C9205 QCB32HK-103 C CAPACITOR 0.01uF 500V K
C9206 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C9207 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9208 NCB31HK-222X C CAPACITOR 2200pF 50V K
 C9209 QCZ9071-471 C CAPACITOR 470pF AC400V K
C9210 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9211 QECR1VM-477Z E CAPACITOR 470uF 35V M
C9212 QEHR1AM-337Z E CAPACITOR 330uF 10V M
C9219 QEHR1VM-107Z E CAPACITOR 100uF 35V M
C9501 QEZ0739-337 E CAPACITOR 330uF
C9502 QCZ0340-331 C CAPACITOR 330pF 2kV K
C9503 QFZ0231-225 MM CAPACITOR 2.2uF
C9504 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9505 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9506 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C9507 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C9508 QEHR1VM-476Z E CAPACITOR 47uF 35V M
C9509 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9510 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9511 QEHR1HM-107Z E CAPACITOR 100uF 50V M
C9512 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9551 QFZ0230-563 MPP CAPACITOR 0.056uF
C9553 NCB31HK-821X C CAPACITOR 820pF 50V K
C9554 NCB31HK-182X C CAPACITOR 1800pF 50V K
C9555 NCB31HK-331X C CAPACITOR 330pF 50V K
C9556 QEHR1CM-107Z E CAPACITOR 100uF 16V M
C9557 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9558 NCB31CK-105X C CAPACITOR 1uF 16V K
C9559 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9560 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C9561 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9562 QEHR1HM-107Z E CAPACITOR 100uF 50V M
 C9591 QCZ9071-102 C CAPACITOR 1000pF AC400V M
C9601 QECQ1VM-128 E CAPACITOR 1200uF 35V M
C9602 QECQ1VM-128 E CAPACITOR 1200uF 35V M
C9603 QECQ1VM-128 E CAPACITOR 1200uF 35V M
C9604 QECQ1VM-128 E CAPACITOR 1200uF 35V M
C9605 QECQ1VM-128 E CAPACITOR 1200uF 35V M
C9612 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C9653 QEHR1HM-336Z E CAPACITOR 33uF 50V M
C9654 QEHR1HM-107Z E CAPACITOR 100uF 50V M
C9701 QECR1VM-337Z E CAPACITOR 330uF 35V M
C9703 QECR1EM-687Z E CAPACITOR 680uF 25V M
C9705 QEHR1CM-477Z E CAPACITOR 470uF 16V M
C9753 QECR1EM-687Z E CAPACITOR 680uF 25V M
C9801 QEZ0476-157 E CAPACITOR 150uF
C9804 QFP32JK-332 PP CAPACITOR 3300pF 630V K
C9805 QFP32JK-332 PP CAPACITOR 3300pF 630V K
C9806 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9807 QEHR1HM-335Z E CAPACITOR 3.3uF 50V M
 Ref No. Part No. Part Name Description Local

JVC LT-52GZ79 Specifications

General

Brand	JVC
Model	LT-52GZ79
Category	TV
Language	English
