1-18 (No.MB519)
3.1.14 Removing the transmitter board
(See Fig.24 and 24)
(1) Remove the two screws W attaching the transmitter board.
(See Fig.24)
(2) Pull up the transmitter board with cable. (See Fig.24)
Fig.24
Fig.25
Bottom case
W
