JVC RV-NB10BJ User Manual

3-13
Micon board (J,C ver.)
Block No. [0][2]
L3191 QQL28AK-101 CHOKE COIL 100uH K
BP1 QQR0768-001Z BP FILTER
BS1 VYH5483-001 SPRING
BS2 VYH7199-001 BATT.SPRING
CF1 QAX0403-001 C FILTER
CN1 QGF1205C2-09 CONNECTOR FFC/FPC (1-9)
CN191 QGA2501C1-09 CONNECTOR W-B (1-9)
CN192 QGB2501K1-04 CONNECTOR B-B (1-4)
CN193 QGA2501C1-05 CONNECTOR W-B (1-5)
CN194 QGA7901C1-02 CONNECTOR W-B (1-2)
CN195 QGA3901C1-02 CONNECTOR W-B (1-2)
CN601 QGF1205F2-13 CONNECTOR FFC/FPC (1-13)
CN602 QGF1205F2-13 CONNECTOR FFC/FPC (1-13)
CN603 QGB1214K1-10S CONNECTOR B-B (1-10)
CN604 QGB1214J1-10S CONNECTOR B-B (1-10)
FW601 WJK0002-001A-E E-SI C WIRE C-B
FW602 WJK0004-001A-E E-SI C WIRE C-B
FW603 WJK0003-001A-E 001A C WIRE C-B
 J1901 QNC0004-001 AC SOCKET
J1902 QNA0016-001 DC JACK
TP1 QNZ0104-001 POST PIN
TP2 QNZ0104-001 POST PIN
WC1 QZW0007-001 POST PIN
 Z1901 QNG0020-001Z FUSE CLIP I.M
 Z1902 QNG0020-001Z FUSE CLIP I.M
 Z1903 QNG0020-001Z FUSE CLIP I.M
 Z1904 QNG0020-001Z FUSE CLIP I.M
 Z1911 QNG0020-001Z FUSE CLIP I.M
 Z1922 QNG0020-001Z FUSE CLIP I.M
 Z1933 QNG0020-001Z FUSE CLIP I.M
 Z1944 QNG0020-001Z FUSE CLIP I.M
 Symbol No. Part No. Part Name Description Local
IC401 NJM4565M-WE IC
IC501 BH3852S IC
IC551 PQ033ES3MX-T IC
IC603 NJM4565M-WE IC
IC751 NJM4565M-WE IC
IC752 NJM4565M-WE IC
IC831 NJM4565M-WE IC
IC901 MN101C49GPY IC(MCU)MASK
IC902 PST9131N-X IC
IC903 GP1UM281XKVF IR DETECT UNIT
IC904 BR24L02F-W-X IC
Q2501 RT1P242C-X TRANSISTOR
Q2501 or KRA108S-X TRANSISTOR
Q2502 2SC3928A/RS/-X TRANSISTOR
Q2502 or 2SD601A/R/-X TRANSISTOR
Q2503 2SC3928A/RS/-X TRANSISTOR
Q2503 or 2SD601A/R/-X TRANSISTOR
Q2504 RT1N440C-X TRANSISTOR
Q2504 or KRC114S-X TRANSISTOR
Q2505 RT1P430C-X TRANSISTOR
Q2505 or KRA110S-X TRANSISTOR
Q3361 2SA1530A/QR/-X TRANSISTOR
 Q3361 or 2SB709A/QR/-X TRANSISTOR
Q3362 2SC3928A/RS/-X TRANSISTOR
Q3362 or 2SD601A/R/-X TRANSISTOR
Q3571 2SB624/4/-X TRANSISTOR
Q3572 2SC3928A/RS/-X TRANSISTOR
Q3572 or 2SD601A/R/-X TRANSISTOR
Q3671 2SB624/4/-X TRANSISTOR
Q3672 RT1N440C-X TRANSISTOR
Q3672 or KRC114S-X TRANSISTOR
Q3791 2SC3928A/RS/-X TRANSISTOR
Q3791 or 2SD601A/R/-X TRANSISTOR
Q4101 2SD596/4/-X TRANSISTOR
Q4101 or 2SD2114K/VW/-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q4102 2SD596/4/-X TRANSISTOR
Q4102 or 2SD2114K/VW/-X TRANSISTOR
Q4201 2SD596/4/-X TRANSISTOR
Q4201 or 2SD2114K/VW/-X TRANSISTOR
Q4202 2SD596/4/-X TRANSISTOR
Q4202 or 2SD2114K/VW/-X TRANSISTOR
Q4301 2SC3928A/RS/-X TRANSISTOR
Q4301 or 2SD601A/R/-X TRANSISTOR
Q5101 2SK301/R/-T JUNCTION FET
Q5201 2SK301/R/-T JUNCTION FET
Q6150 2SD596/4/-X TRANSISTOR
Q6150 or 2SD2114K/VW/-X TRANSISTOR
Q6151 2SD596/4/-X TRANSISTOR
Q6151 or 2SD2114K/VW/-X TRANSISTOR
Q6250 2SD596/4/-X TRANSISTOR
Q6250 or 2SD2114K/VW/-X TRANSISTOR
Q6251 2SD596/4/-X TRANSISTOR
Q6251 or 2SD2114K/VW/-X TRANSISTOR
Q6350 RT1N141C-X TRANSISTOR
Q6350 or UN2211-X TRANSISTOR
Q6351 RT1P141C-X TRANSISTOR
Q6351 or UN2111-X TRANSISTOR
Q6401 RT1N141C-X TRANSISTOR
Q6401 or UN2211-X TRANSISTOR
Q7351 2SC3928A/RS/-X TRANSISTOR
Q7351 or 2SD601A/R/-X TRANSISTOR
Q7352 2SC3928A/RS/-X TRANSISTOR
Q7352 or 2SD601A/R/-X TRANSISTOR
Q7353 RT1P241C-X TRANSISTOR
Q7353 or UN2112-X TRANSISTOR
Q7354 2SC3928A/RS/-X TRANSISTOR
Q7354 or 2SD601A/R/-X TRANSISTOR
Q7355 RT1P241C-X TRANSISTOR
Q7355 or UN2112-X TRANSISTOR
Q7356 2SC3928A/RS/-X TRANSISTOR
Q7356 or 2SD601A/R/-X TRANSISTOR
Q7357 2SC3928A/RS/-X TRANSISTOR
Q7357 or 2SD601A/R/-X TRANSISTOR
Q7358 2SC3928A/RS/-X TRANSISTOR
Q7358 or 2SD601A/R/-X TRANSISTOR
Q7359 2SA1530A/QR/-X TRANSISTOR
Q7359 or 2SB709A/QR/-X TRANSISTOR
Q7360 DTC115EKA-X DIGI TRANSISTOR
Q8351 2SA1530A/QR/-X TRANSISTOR
Q8351 or 2SB709A/QR/-X TRANSISTOR
Q8352 2SA1530A/QR/-X TRANSISTOR
Q8352 or 2SB709A/QR/-X TRANSISTOR
Q8353 2SC3928A/RS/-X TRANSISTOR
Q8353 or 2SD601A/R/-X TRANSISTOR
Q8354 RT1N141C-X TRANSISTOR
Q8354 or UN2211-X TRANSISTOR
Q9001 KTC3195/O/-T TRANSISTOR
Q9002 KTC3195/O/-T TRANSISTOR
Q9003 2SA1530A/QR/-X TRANSISTOR
Q9003 or 2SB709A/R/-X TRANSISTOR
Q9004 2SC3928A/RS/-X TRANSISTOR
Q9004 or 2SD601A/R/-X TRANSISTOR
Q9005 2SC3928A/RS/-X TRANSISTOR
Q9005 or 2SD601A/R/-X TRANSISTOR
Q9006 2SC3928A/RS/-X TRANSISTOR
Q9006 or 2SD601A/R/-X TRANSISTOR
D2502 SLR-342VR-T15 LED I M
D2503 SLR-342VR-T15 LED I M
D2504 SLR-342MG-T15 LED I M
D3361 1SS133-T2 SI DIODE IM
D3362 MTZJ3.9B-T2 Z DIODE
D3363 1SS133-T2 SI DIODE IM
D3571 SELU1E54CM-P LED
D3572 SELU1E54CM-P LED
D3791 MTZJ6.2A-T2 Z DIODE
D4301 1SS133-T2 SI DIODE IM
D4302 1SS133-T2 SI DIODE IM
D5501 1SS133-T2 SI DIODE IM
D6303 1SS133-T2 SI DIODE IM
D6501 MTZJ4.7A-T2 Z DIODE
D6502 MTZJ3.6A-T2 ZENER DIODE IM
D6503 1SS133-T2 SI DIODE IM
 Symbol No. Part No. Part Name Description Local

JVC RV-NB10BJ Specifications

General

Brand	JVC
Model	RV-NB10BJ
Category	CD Player
Language	English
