3-11
Electrical parts list
Main board (J,C ver.)
Block No. [0][1]
 Symbol No. Part No. Part Name Description Local
 IC301 TA8233BH IC
 IC390 KIA78DL06PI IC
 IC601 TA8223K IC
IC701 BA15218N IC
IC702 BA15218N IC
IC703 BA15218N IC
IC704 BA15218N IC
IC801 BA15218N IC
Q3191 KRA110M-T TRANSISTOR
 Q3192 2SA1359/OY/ TRANSISTOR
Q3193 KRA111M-T DIGI TRANSISTOR
Q3194 KTC3199/GL/-T TRANSISTOR
Q3195 KTA1267/YG/-T TRANSISTOR
 Q3196 KTA1023/OY/-T TRANSISTOR
Q3197 KTC3199/GL/-T TRANSISTOR
Q3198 KRC111M-T TRANSISTOR
Q3301 KTA1267/YG/-T TRANSISTOR
 Q3302 2SA1359/OY/ TRANSISTOR
Q3303 KRA114M-T DIGI TRANSISTOR
Q3304 KRC114M-T TRANSISTOR
Q3305 KTC3199/GL/-T TRANSISTOR
Q3306 KTC3199/GL/-T TRANSISTOR
Q3491 KTA1267/YG/-T TRANSISTOR
 Q3492 KTA1046/Y/ TRANSISTOR *
Q3493 KRA114M-T DIGI TRANSISTOR
Q3494 KRC114M-T TRANSISTOR
Q3495 KTC3199/GL/-T TRANSISTOR
Q3496 KTC3199/GL/-T TRANSISTOR
Q6101 KTC3203/OY/-T TRANSISTOR
Q6201 KTC3203/OY/-T TRANSISTOR
Q6301 2SA952/LK/-T TRANSISTOR
Q6302 KTC3199/GL/-T TRANSISTOR
Q6303 KRA102M-T DIGI TRANSISTOR
Q6304 KTC3203/OY/-T TRANSISTOR
Q6305 KRC102M-T DIGI TRANSISTOR
Q6306 KRC102M-T DIGI TRANSISTOR
Q6307 KRC102M-T DIGI TRANSISTOR
Q6308 KRC102M-T DIGI TRANSISTOR
Q7301 KTC3199/GL/-T TRANSISTOR
Q7302 KTC3199/GL/-T TRANSISTOR
Q7303 2SK301/R/-T JUNCTION FET
Q8101 KTC3199/GL/-T TRANSISTOR
Q8201 KTC3199/GL/-T TRANSISTOR
D8 SVC344-T VARI CAP
 D1901 TS6P05G-07 SI DIODE
D1902 6A10E2 SI DIODE
D3191 1SS133-T2 SI DIODE
D3192 MTZJ7.5A-T2 Z DIODE
D3193 SRT14 DIODE
D3194 MTZJ7.5A-T2 Z DIODE
D3195 1SS133-T2 SI DIODE
D3196 1SS133-T2 SI DIODE
D3301 1SS133-T2 SI DIODE
D3302 MTZJ9.1A-T2 Z DIODE
D3491 1SS133-T2 SI DIODE
D3492 MTZJ9.1A-T2 Z DIODE
D3493 1SS133-T2 SI DIODE
D3901 MTZJ8.2B-T2 Z DIODE
D6301 1SS133-T2 SI DIODE
D6302 1SS133-T2 SI DIODE
D6304 1SS133-T2 SI DIODE
D7301 1SS133-T2 SI DIODE
D7302 1SS133-T2 SI DIODE
D7303 1SS133-T2 SI DIODE
D7304 1SS133-T2 SI DIODE
D7305 1SS133-T2 SI DIODE
D7306 1SS133-T2 SI DIODE
D7307 MTZJ4.3B-T2 Z DIODE
D8301 MTZJ4.3B-T2 Z DIODE
 C1901 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
 C1902 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
 C1903 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
 C1904 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
C3191 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C3192 QETN1EM-107Z E CAPACITOR 100uF 25V M
C3193 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C3194 QETN1EM-107Z E CAPACITOR 100uF 25V M
C3301 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C3302 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C3303 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3491 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C3492 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C3493 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3901 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3902 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C5308 QER61HM-474Z E CAPACITOR 0.47uF 50V M
C6101 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C6102 QCBB1HK-151Y C CAPACITOR 150pF 50V K
C6103 QETN1EM-107Z E CAPACITOR 100uF 25V M
C6104 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6105 QETN1EM-476Z E CAPACITOR 47uF 25V M
C6106 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C6107 QTE1V06-226Z E CAPACITOR 22uF 35V
C6201 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C6202 QCBB1HK-151Y C CAPACITOR 150pF 50V K
C6203 QETN1EM-107Z E CAPACITOR 100uF 25V M
C6204 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6205 QETN1EM-476Z E CAPACITOR 47uF 25V M
C6206 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C6207 QTE1V06-226Z E CAPACITOR 22uF 35V
C6301 QETN1EM-227Z E CAPACITOR 220uF 25V M
C6302 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6303 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6304 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J
C6305 QETN1HM-105Z E CAPACITOR 1uF 50V M
C6306 QETN1AM-227Z E CAPACITOR 220uF 10V M
C6307 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6308 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C6309 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C6310 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C6311 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6312 QETN1EM-227Z E CAPACITOR 220uF 25V M
C6313 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C6314 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
 C6315 QETM1EM-688 E CAPACITOR 6800uF 25V M
C6316 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6317 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6318 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6319 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6320 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6321 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7301 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7302 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C7303 QCSB1HK-3R3Y C CAPACITOR 3.3pF 50V K
C7305 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7306 QFVF1HJ-274Z MF CAPACITOR 0.27uF 50V J
C7307 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7308 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C7309 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7310 QFLC1HJ-153Z M CAPACITOR 0.015uF 50V J
C7311 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7312 QETN1HM-105Z E CAPACITOR 1uF 50V M
C7313 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7314 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7316 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7317 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C7318 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7319 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C7320 QFLC1HJ-393Z M CAPACITOR 0.039uF 50V J
C7321 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J
C7322 QER61HM-105Z E CAPACITOR 1uF 50V M
C7323 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7324 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
 Symbol No. Part No. Part Name Description Local
