JVC SR-VS30E Service Manual

5-1
SECTION 5
PARTS LIST
SAFETY PRECAUTION
Parts identified by the ! symbol are critical for safety. Replace only with specified part numbers.
5.1 PACKING AND ACCESSORY ASSEMBLY <M1>
The instruction manual to be provided with this product will differ according to the destination.
******************************
PACKING AND ACCESSORY ASSEMBLY <M1>
301 LP31052-011A PACKING CASE,VS30E
LP31052-012A PACKING CASE,VS30EK
302 LP31053-001B CUSHION 1
303 PQM30021-105 POLY BAG
304 LP31054-001B CUSHION 2
306 LP20873-016A REMOTE CONTROLLER
306A LP40254-004A COVER(BATTERY)
307 – BATTERY,X2(“R6”TYPE)
308 QPC02202230P POLY BAG
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
! 309 LPT0678-001A INST.BOOK(EN),VS30E
! LPT0679-001A INST.BOOK(EN),VS30EK
! 310 LPT0678-002A INST.BOOK(GE),VS30E
! 311 LPT0678-003A INST.BOOK(FR),VS30E
! 312 LPT0678-004A INST.BOOK(SP),VS30E
! 313 LPT0678-005A INST.BOOK(IT),VS30E
314 PEAC0300-02 RF CABLE
315 QAL0095-005 LED CABLE ASSY
317 QAM0123-001 PERI PIN CABLE
318 QPC02503530P POLY BAG
319 LP31118-001A SHEET,VS30E
320 QAM0259-001 ADAPTOR PLUG,X2
SPEC OF BARCODE
301
304
BEND AS SHOWN IN THE DRAWING.
FINAL ASSY <M2>
303
ADHESIVE T
SR-VS30ESR-VS30EK
DANPHRON TAPE
APE
307
308
306
302
302
304
314
315
306A
INSERT
TUCK IN
(Fig.1)
(Fig.1)
Fig.1
B' F' E' A'
B
JD' J'D
Q'
Q
RP
K
L
N'
S'
M'
ADZ
ES
R'
C' H GG'H'
C
N
M
L'K'
P'
F
Z'
Z
A
E
E
317
320 x2
313
312
311
310
309
318
319
309
318
