JVC SR-VS30E Service Manual

5-17
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
C6553 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C7502 QETJ0JM-477 E CAPACITOR 470µF,6.3V
L1 QQL29BJ-100Z COIL 10µH
L2 QQL071J-121Y COIL 120µH
L3 QQL29BJ-100Z COIL 10µH
L4 QQL29BJ-100Z COIL 10µH
L5 QQR0521-012Z NOISE FILTER
L12 QQR0967-001 COIL
L13 QQL071J-330Y COIL 33µH
L15 QQL29BJ-100Z COIL 10µH
L18 QQL071J-220Y COIL 22µH
L19 QQL071J-120Y COIL 12µH
L20 QUY153-050Y IM BUS WIRE
L24 QQL071J-270Y COIL 27µH
L27 QQL071J-330Y COIL 33µH
L28 QQL071J-680Y COIL 68µH
L30 QUY153-050Y IM BUS WIRE
L201 QQL29BK-1R0Z COIL 1.0µH
L202 QUY153-050Y IM BUS WIRE
L203 QQL071J-220Y COIL 22µH
L204 QQL29BJ-100Z COIL 10µH
L205 QUY153-050Y IM BUS WIRE
L206 QQL29BJ-220Z COIL 22µH
L401 QQL071J-150Y COIL 15µH
L402 QUY153-050Y IM BUS WIRE
L601 QQL29BJ-100Z COIL 10µH
L701 QQL29BJ-100Z COIL 10µH
L702 QQL29BJ-100Z COIL 10µH
L703 QQL29BJ-100Z COIL 10µH
L704 QQL29BJ-100Z COIL 10µH
L705 QQL29BJ-100Z COIL 10µH
L2001 QUY153-050Y IM BUS WIRE
L2251 QQL29BJ-100Z COIL 10µH
L2252 QQL29BJ-151Z COIL 150µH
L3001 QUY153-050Y IM BUS WIRE
L6001 QQL29BJ-100Z COIL 10µH
L6002 QQL29BJ-100Z COIL 10µH
L6005 QQL29BJ-100Z COIL 10µH
L6032 QUY153-050Y IM BUS WIRE
L6501 QQL29BJ-3R3Z COIL 3.3µH
L7501 QQL29BJ-101Z COIL 100µH
X1 QAX0576-001Z CRYSTAL RESONATOR
X3001 QAX0444-001 CRYSTAL RESONATOR,VS30EK
QAX0445-001 CRYSTAL RESONATOR,VS30E
X3002 QAX0527-001 CRYSTAL RESONATOR
S3001 QSW0602-004 PUSH SWITCH,REC SAFETY
S3002 QSW0695-001 PUSH SWITCH,S CASS SW
K2001 NQL103K-R10X COIL 0.1µH
K2002 NQL103K-R10X COIL 0.1µH
K2003 NQL103K-R10X COIL 0.1µH
K2004 NQL103K-R10X COIL 0.1µH
K2251 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
K2252 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
K2253 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
PC3001 GP3S123 IC(PHOTO SENSOR)
PC3002 GP3S123 IC(PHOTO SENSOR)
T2051 PELN0860 OSC TRANSFORMER
T2052 PELN0861 OSC TRANSFORMER
TU6001 QAU0209-002 TUNER
SD1 LP30644-001A S.CASE(PRE)
OT1 QYTDSF3010Z SCREW,X2,TERMINAL
OT2 LP40229-002A PLATE
ST2 PU59391 STYLE PIN
ET1 PQ21623-2-5 EARTH PLATE(RF)
WR100 QUQ112-0912CG FFC WIRE,TERMINAL CN901
WR101 QUQ112-1514CG FFC WIRE,TERMINAL CN502
CN1 QGF1028C1-13 FPC CONNECTOR,(1-13)DRUM
CN701 QGF1207C1-14 FPC CONNECTOR,(1-14)DV MAIN
CN2001 QGF1207C1-07 FPC CONNECTOR,(1-7)A/C HEAD
CN2002 QGB2532J1-02 CONNECTOR,(1-2)FE HEAD
CN2601 QGF1016C3-08 FFC/FPC CONNECTOR,(1-8)DV MAIN
CN3001 QGF1207C1-05 FPC CONNECTOR,(1-5)DRUM MDA
CN3002 QGB2532J1-02 CONNECTOR,(1-2)LOADING MOTOR
CN3003 QGB2015M2-08 CONNECTOR,(1-8)CAPSTAN MOTOR
CN3004 QGB2534J2-04 CONNECTOR,(1-4)ROTALY ENCODER
CN3011 QGF1209F2-20
FFC/FPC CONNECTOR,(1-20)SW/DISPALY
CN3014 QGF1207C1-04 FPC CONNECTOR,(1-4)DV MAIN
CN7501 QGB2024K1-09S CONNECTOR,(1-9)TERMINAL
CN7502 QGB2024K1-10S CONNECTOR,(1-10)TERMINAL
CN7503 QGB2024K1-12S CONNECTOR,(1-12)TERMINAL
CN7504 QGB2024K1-11S CONNECTOR,(1-11)TERMINAL
CN7505 QGB2024K1-09S CONNECTOR,(1-9)TERMINAL
CN7506 QGF1207C1-15 FPC CONNECTOR,(1-15)TERMINAL
CN7507 QGF1207C1-09 FPC CONNECTOR,(1-9)TERMINAL
CN7508 QGF1207C1-10 FPC CONNECTOR,(1-10)SW REG
CN7509 QGF1207C1-12 FPC CONNECTOR,(1-12)SW REG
CN7510 QGF1209F2-10 FPC CONNECTOR,(1-10)SW/DISPLAY
! CP3003 ICP-N25 CIRCUIT PROTECTOR
! CP3004 ICP-N25 CIRCUIT PROTECTOR
! CP4001 ICP-N25 CIRCUIT PROTECTOR
******************************
3D DIGITAL/2M BOARD ASSEMBLY <05>
PW1 LPA10105-05A 3D DIGITAL/2M BOARD ASSY
IC1401 JCP8026 IC
Q1401 2SC1317/RS/-T TRANSISTOR
Q1402 2SA1576A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q1403 2SA1576A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q1404 DTC144WU DIGI TRANSISTOR
or RN1309 DIGI TRANSISTOR
or UN521E DIGI TRANSISTOR
Q1406 2SA1576A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q1407 2SA1576A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q1408 2SC4081/S/-X TRANSISTOR
Q1410 2SC4081/QRS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
Q1412 2SC4081/QRS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
Q1413 2SA1576A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q1414 DTC144WU DIGI TRANSISTOR
or RN1309 DIGI TRANSISTOR
or UN521E DIGI TRANSISTOR
Q1417 2SC4081/QRS/-X TRANSISTOR
