JVC SR-VS30E Service Manual

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-22
R7055 QRE141J-331Y RESISTOR 330Ø,1/4W
R7056 QRE141J-331Y RESISTOR 330Ø,1/4W
R7057 QRE141J-331Y RESISTOR 330Ø,1/4W
R7058 QRE141J-331Y RESISTOR 330Ø,1/4W
R7191 QRE141J-750Y RESISTOR 75Ø,1/4W
R7192 QUY153-050Y IM BUS WIRE
R7193 QRE141J-750Y RESISTOR 75Ø,1/4W
R7194 QRE141J-750Y RESISTOR 75Ø,1/4W
B7001 QUY153-050Y IM BUS WIRE
C7001 QCFB1HZ-104 CAPACITOR 0.1µF,50V
C7007 QERF0JM-476 E CAPACITOR 47µF,6.3V
C7010 QCFB1HZ-104 CAPACITOR 0.1µF,50V
C7011 QEKJ0JM-227 E CAPACITOR 220µF,6.3V
C7019 QDVB1EZ-223Y CAPACITOR 0.022µF,25V
C7023 QERF1HM-106 E CAPACITOR 10µF,50V
C7192 QCBB1HK-681 CAPACITOR 680pF,50V
C7194 QCBB1HK-681 CAPACITOR 680pF,50V
C7196 QDYB1CM-103Y CAPACITOR 0.01µF,16V
L7001 QQL29BK-1R0Z COIL 1.0µH
L7002 QUY153-050Y IM BUS WIRE
L7191 QRE141J-101Y RESISTOR 100Ø,1/4W
L7192 QRE141J-101Y RESISTOR 100Ø,1/4W
L7193 QUY153-050Y IM BUS WIRE
L7194 QUY153-050Y IM BUS WIRE
S7004 QSW0456-002Z TACT SWITCH,REC
S7005 QSW0456-002Z TACT SWITCH,PAUSE
S7006 QSW0456-002Z TACT SWITCH,PLAY
S7007 QSW0456-002Z TACT SWITCH,STOP
S7008 QSW0456-001Z TACT SWITCH,I-O/R-SPD
S7009 QSW0456-001Z TACT SWITCH,ST/CANCEL
S7010 QSW0456-002Z TACT SWITCH,DV/HDD
S7011 QSW0456-002Z TACT SWITCH,VHS EJECT
S7012 QSW0456-002Z TACT SWITCH,EXP.T/MENU
S7013 QSW0456-002Z TACT SWITCH,VHS
S7015 QSW0456-001Z TACT SWITCH,RAE/SUMBNL
S7016 QSW0456-001Z TACT SWITCH,INS/R-LINK
S7017 QSW0456-001Z TACT SWITCH,A.DUB
S7021 QSW0456-002Z TACT SWITCH,DV>VHS/REW
S7022 QSW0456-002Z TACT SWITCH,DV<VHS/FF
S7023 QSW0456-002Z TACT SWITCH,DUB
DI7001 QLF0031-002 FL TUBE
HD1 PQ34949 FDP HOLDER(L),DI7001
HD2 PQ34950 FDP HOLDER(R),DI7001
HD3 PQM30038-2-2 LED HOLDER,D7009
HD4 PQM30038-2-2 LED HOLDER,D7010
HD5 PQM30038-2-2 LED HOLDER,D7011
HD6 PQM30038-2-2 LED HOLDER,D7012
HD7 PQM30038-2-2 LED HOLDER,D7013
HD8 PQM30038-2-2 LED HOLDER,D7014
HD9 PQM30038-2-2 LED HOLDER,D7015
HD10 PQM30038-2-2 LED HOLDER,D7016
FW7001 QUM023-12A4A4 P.R.WIRE,(1-3)POWER SW
FW7003 QUM024-08A4A4 P.R WIRE,(1-4)JOG
J7191 QNN0371-004 PIN JACK,FRONT V IN
J7192 QNN0371-003 PIN JACK,FRONT L IN
J7193 QNN0372-002 PIN JACK,FRONT R IN
J7194 QND0085-001 S JACK,FRONT S IN
J7195 PU60659 MINI JACK,PAUSE
CN7001 QGF1201C1-20 FPC CONNECTOR,(1-20)VHS MAIN
CN7191 QGF1201F1-10 FPC CONNECTOR,(1-10)VHS MAIN
******************************
DV MAIN BOARD ASSEMBLY <50>
PW1 LPA10165-04A DV MAIN BOARD ASSY
IC1001 MM1561JF IC
IC1002 MM1572FN IC
IC1003 MM1573AN IC
IC1004 MM1572KN IC
IC1005 S-80823ANNP-W IC
IC1501 MN103004KFF IC
or MN1030F04KHFFF IC
IC1502 TC7W14FK IC
IC1503 TC7W04FU IC(DIGITAL)
IC1504 25LC040-I/SN-X IC
IC2001 JCY0176 IC
IC2002 JCY0136 IC
IC2007 TLC2940IPW IC
IC3001 JCP8029 IC
IC3101 TC7SH04F IC(DIGITAL)
IC3102 TC7SH04F IC(DIGITAL)
IC3151 M62366GP IC
IC3501 NJM2538V IC
IC3701 AK4518-VF-X IC
IC3702 BA15218F-XE IC
IC3703 BA15218F-XE IC
IC4001 JCY0132 IC
IC4002 TC7SH00FU IC(DIGITAL)
Q1001 2SB1302/ST/-X TRANSISTOR
Q1002 DTC144EE DIGI TRANSISTOR
Q1003 2SB1302/ST/-X TRANSISTOR
Q1004 DTC144EE DIGI TRANSISTOR
Q1005 2SB1302/ST/-X TRANSISTOR
Q1006 DTC144EE DIGI TRANSISTOR
Q1007 2SB1302/ST/-X TRANSISTOR
Q1008 DTC144EE DIGI TRANSISTOR
Q1501 2SC4617/RS/-X TRANSISTOR
Q1502 2SC4617/RS/-X TRANSISTOR
Q1511 DTA114EE DIGI TRANSISTOR
Q1512 UMC3N DIGI TRANSISTOR
Q1513 UMC3N DIGI TRANSISTOR
Q3101 2SA1576A/RS/-X TRANSISTOR
Q3102 2SA1576A/RS/-X TRANSISTOR
Q3111 2SA1576A/RS/-X TRANSISTOR
Q3112 HN1B04FU/YG/-X PAIR TRANSISTOR
Q3113 2SC4081/RS/-X TRANSISTOR
Q3114 2SC4081/S/-X TRANSISTOR
Q3115 DTC144EE DIGI TRANSISTOR
Q3131 2SA1576A/RS/-X TRANSISTOR
Q3132 HN1B04FU/YG/-X PAIR TRANSISTOR
Q3133 2SC4081/RS/-X TRANSISTOR
Q3135 DTC144EE DIGI TRANSISTOR
Q3501 DTC144EE DIGI TRANSISTOR
Q3502 2SA1576A/RS/-X TRANSISTOR
Q3503 2SA1576A/RS/-X TRANSISTOR
D1501 SB007W03Q SB DIODE
D1502 SB007W03Q SB DIODE
D1503 SB007W03Q SB DIODE
D2002 EC2C01C VARI CAP DIODE
D2003 EC2C01C VARI CAP DIODE
D2004 EC2C01C VARI CAP DIODE
