JVC SR-VS30E Service Manual

5-9
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
R5106 QRT01DJ-R39X MF RESISTOR 0.39Ø,1W
R5107 QRE121J-331Y RESISTOR 330Ø,1/2W
R5108 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W
R5109 QRE141J-681Y RESISTOR 680Ø,1/4W
R5110 NRSA02J-224X MG RESISTOR 220kØ,1/10W
R5111 NRSA02J-681X MG RESISTOR 680Ø,1/10W
R5112 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R5201 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R5202 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R5203 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5204 NRVA02D-332X CMF RESISTOR 3.3kØ,1/10W
R5205 NRVA02D-123X CMF RESISTOR 12kØ,1/10W
R5206 NRVA02D-332X CMF RESISTOR 3.3kØ,1/10W
R5207 QRE141J-3R3Y RESISTOR 3.3Ø,1/4W
! R5208 QRZ9005-221X FUSI RESISTOR 220Ø,1/4W
R5209 QRE121J-331Y RESISTOR 330Ø,1/2W
R5210 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5211 QRE121J-331Y RESISTOR 330Ø,1/2W
R5212 QRE121J-331Y RESISTOR 330Ø,1/2W
R5213 NRSA02J-473X MG RESISTOR 47kØ,1/10W
R5321 NRSA02J-473X MG RESISTOR 47kØ,1/10W
R5322 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R5323 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R5324 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5325 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R5326 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R5327 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R5328 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5329 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R5330 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R5331 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5332 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R5333 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5336 NRVA02D-472X CMF RESISTOR 4.7kØ,1/10W
R5337 NRVA02D-102X CMF RESISTOR 1kØ,1/10W
R5338 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R5340 QRL01DJ-820X OMF RESISTOR 82Ø,1W
R5341 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5342 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W
R5343 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R5344 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5348 NRSA02J-273X MG RESISTOR 27kØ,1/10W
R5349 QRE141J-273Y RESISTOR 27kØ,1/4W
B5302 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
! C5001 QFZ9073-683 F CAPACITOR 0.068µF,250V
! C5002 QFZ9051-333 F CAPACITOR 0.033µF,250V
! C5004 QCZ9071-222 CAPACITOR 0.0022µF,400V
C5006 QEZ0374-826 E CAPACITOR 82µF,400V
C5101 QCZ0212-472 CAPACITOR 0.0047µF,1kV
C5102 QCZ0136-101Z CAPACITOR 100pF,1kV
C5104 QETN1HM-105 E CAPACITOR 1µF,50V
C5105 QFN31HJ-183 F CAPACITOR 0.018µF,50V
C5106 QCBB1HJ-271 CAPACITOR 270pF,50V
C5107 QFV91HJ-104 F CAPACITOR 0.1µF,50V
C5201 QFV91HJ-154 F CAPACITOR 0.15µF,50V
C5202 NCB21HK-103X CAPACITOR 0.01µF,50V
C5203 QEMU0JM-227 E CAPACITOR 220µF,6.3V
C5204 QEMT1AM-278 E CAPACITOR 2700µF,10V
C5205 QEMT1CM-827 E CAPACITOR 820µF,16V
C5206 QEMU1EM-187 E CAPACITOR 180µF,25V
C5207 QETN2AM-475 E CAPACITOR 4.7µF,100V
C5208 QEMU1HM-186 E CAPACITOR 18µF,50V
C5209 QETN1AM-107 E CAPACITOR 100µF,10V
C5210 QETN1CM-107 E CAPACITOR 100µF,16V
C5211 QETN1AM-107 E CAPACITOR 100µF,10V
C5321 QETN1AM-107 E CAPACITOR 100µF,10V
C5322 QETN1HM-225 E CAPACITOR 2.2µF,50V
C5323 QETN1CM-107 E CAPACITOR 100µF,16V
C5324 NCB21HK-102X CAPACITOR 0.001µF,50V
C5325 NCB21HK-102X CAPACITOR 0.001µF,50V
C5326 QETN1AM-107 E CAPACITOR 100µF,10V
C5329 NCB21HK-103X CAPACITOR 0.01µF,50V
C5330 QETN1AM-107 E CAPACITOR 100µF,10V
C5331 QETN1AM-107 E CAPACITOR 100µF,10V
L5201 PELN1184 COIL 33µH
L5202 QQR1169-001 COIL
L5203 PELN1184 COIL 33µH
K5101 QQR0678-001Z FERRATE BEADS
K5102 QQR0678-001Z FERRATE BEADS
! PC5101 PC123F2 IC(PHOTO COUPLER)
! T5001 QQS0031-002 SW TRANSF
HS1 LP40090-001A HEAT SINK,Q5101
HS2 LP40090-001A HEAT SINK,D5203
OT1 QYTDST3006Z SCREW,Q5101
OT2 QYTDST3006Z SCREW,D5203
FC5001 QNG0006-001Z FUSE CLIP,F5001
FC5002 QNG0006-001Z FUSE CLIP,F5001
! LF5001 PELN1204-01-01 LINE FILTER
! LF5002 QQR1031-001 LINE FILTER
! CN5001 QGA7901C3-02 CONNECTOR,(1-2)AC IN
CN5321 QGF1208C1-12 FPC CONNECTOR,(1-12)VHS MAIN
CN5322 QGF1208C1-10 FPC CONNECTOR,(1-10)VHS MAIN
CN5323 QGF1208C1-08 FPC CONNECTOR,(1-8)VHS MAIN
CN5324 QGA2001C1-05 CONNECTOR,(1-5)MDA
CN5325 QGA2001C1-02 CONNECTOR,(1-2)FAN
! CP5321 NMFZ012-1R0X-M FUSE T1.0A,50V
! CP5322 NMFZ012-1R0X-M FUSE T1.0A,50V
! CP5325 NMFZ012-1R0X-M FUSE T1.0A,50V
! F5001 QMF51E2-2R0J1 FUSE T2.0A,AC250V
******************************
MAIN BOARD ASSEMBLY <03>
PW1 MAIN BOARD ASS’Y<03> includes the parts shown in the following.
PW1 3D DIGITAL/2M BOARD ASS’Y<05>
PW1 TERMINAL BOARD ASS’Y<06>
PW1 DEMOD BOARD ASS’Y<14>
PW1 LPA10149-08A MAIN BOARD ASSY,VS30E
LPA10149-09A MAIN BOARD ASSY,VS30EK
IC1 JCP8050-MSA IC
IC201 LC74775-9750 IC
IC601 VC2076DP IC
IC701 MM1501XN IC
IC702 MM1503XN IC
IC703 MM1503XN IC
IC704 MM1504XN IC
IC705 MM1111XF IC
IC706 MM1115XF IC
IC2601 BA15218F-XE IC
IC2602 BU4052BCF IC
