JVC SR-VS30E Service Manual

5-21
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
D6701 1SS133 DIODE
or 1N4148M DIODE
R6701 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W
R6702 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W
R6703 NRSA02J-470X MG RESISTOR 47Ø,1/10W
R6704 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R6705 NRSA02J-271X MG RESISTOR 270Ø,1/10W
R6706 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R6707 NQR0200-003X FERRITE BEAD
R6708 NQR0200-003X FERRITE BEAD
R6709 NQR0200-003X FERRITE BEAD
R6710 NQR0200-003X FERRITE BEAD
R6711 NRSA02J-684X MG RESISTOR 680kØ,1/10W
R6712 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R6714 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R6716 NQR0200-003X FERRITE BEAD
R6719 QRE141J-103Y RESISTOR 10kØ,1/4W
R6720 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W
R6721 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W
C6701 NCB21HK-103X CAPACITOR 0.01µF,50V
C6704 NCB21HK-103X CAPACITOR 0.01µF,50V
C6705 NCB21HK-102X CAPACITOR 0.001µF,50V
C6707 NDC21HJ-470X CAPACITOR 47pF,50V
C6708 NDC21HJ-7R0X CAPACITOR 7pF,50V
C6709 NDC21HJ-3R0X CAPACITOR 3pF,50V
C6713 NCF21CZ-224X CAPACITOR 0.22µF,16V
C6714 NCB21HK-222X CAPACITOR 0.0022µF,50V
C6715 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C6716 NCB21HK-222X CAPACITOR 0.0022µF,50V
C6717 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C6719 QEKJ1EM-106 E CAPACITOR 10µF,25V
C6720 QEKJ1EM-106 E CAPACITOR 10µF,25V
C6721 NCB21HK-103X CAPACITOR 0.01µF,50V
C6723 NCB21HK-103X CAPACITOR 0.01µF,50V
L6701 QUY153-050Y IM BUS WIRE
L6702 QQL231J-3R3Y COIL 3.3µH
X6701 QAX0443-001 CRYSTAL RESONATOR
K6701 NRSA02J-330X MG RESISTOR 33Ø,1/10W
K6702 NQR0200-003X FERRITE BEAD
K6703 NRSA02J-102X MG RESISTOR 1kØ,1/10W
K6704 NRSA02J-102X MG RESISTOR 1kØ,1/10W
K6705 NRSA02J-100X MG RESISTOR 10Ø,1/10W
K6706 NRSA02J-470X MG RESISTOR 47Ø,1/10W
BK1 LP40425-001A BRACKET(BOARD)
CN6701 QGG2502K1-10 HEADER PIN,(1-10)MAIN
******************************
POWER SW BOARD ASSEMBLY <27>
PW2 LPA10150-01A2 POWER SW BOARD ASSY
S7001 QSW0456-002Z TACT SWITCH,POWER
S7014 QSW0456-002Z TACT SWITCH,DV EJECT
******************************
SW/DISPLAY BOARD ASSEMBLY <28>
PW1 LPA10150-01B1 SW/DISPLAY BOARD ASSY
IC7001 M35500BFP IC
or M35500BGP IC
or M35500AGP IC
IC7002 GP1U281X IR DETECT UNIT
or PNA4652M00XB IR DETECT UNIT
D7002 RD9.1ES/B2/-T2 ZENER DIODE
or MTZJ9.1B ZENER DIODE
D7004 1SS133 DIODE
or 1SS270A DIODE
D7005 1SS133 DIODE
or 1SS270A DIODE
D7006 1SS133 DIODE
or 1SS270A DIODE
D7009 SLR-342DC3F LE DIODE
D7010 SLR-342MC3F LE DIODE
D7011 SLR-342VC3F LE DIODE
D7012 SLR-342DC3F LE DIODE
D7013 SLR-342MC3F LE DIODE
D7014 SLR-342VC3F LE DIODE
D7015 SLR-342MC3F LE DIODE
D7016 SLR-342MC3F LE DIODE
R7001 QRE141J-471Y RESISTOR 470Ø,1/4W
R7002 QRE141J-471Y RESISTOR 470Ø,1/4W
R7003 QRE141J-471Y RESISTOR 470Ø,1/4W
R7004 QRE141J-471Y RESISTOR 470Ø,1/4W
R7006 QRE141J-103Y RESISTOR 10kØ,1/4W
R7007 QRE141J-103Y RESISTOR 10kØ,1/4W
R7008 QRE141J-103Y RESISTOR 10kØ,1/4W
R7013 QRE141J-103Y RESISTOR 10kØ,1/4W
R7014 QRE141J-0R0Y RESISTOR 0Ø,1/4W
R7015 QRE141J-0R0Y RESISTOR 0Ø,1/4W
R7020 QRE141J-103Y RESISTOR 10kØ,1/4W
R7021 QRE141J-122Y RESISTOR 1.2kØ,1/4W
R7022 QRE141J-182Y RESISTOR 1.8kØ,1/4W
R7023 QRE141J-222Y RESISTOR 2.2kØ,1/4W
R7024 QRE141J-272Y RESISTOR 2.7kØ,1/4W
R7025 QRE141J-472Y RESISTOR 4.7kØ,1/4W
R7026 QRE141J-682Y RESISTOR 6.8kØ,1/4W
R7027 QRE141J-153Y RESISTOR 15kØ,1/4W
R7028 QRE141J-393Y RESISTOR 39kØ,1/4W
R7030 QRE141J-103Y RESISTOR 10kØ,1/4W
R7031 QRE141J-122Y RESISTOR 1.2kØ,1/4W
R7032 QRE141J-182Y RESISTOR 1.8kØ,1/4W
R7033 QRE141J-222Y RESISTOR 2.2kØ,1/4W
R7034 QRE141J-272Y RESISTOR 2.7kØ,1/4W
R7035 QRE141J-472Y RESISTOR 4.7kØ,1/4W
R7036 QRE141J-682Y RESISTOR 6.8kØ,1/4W
R7037 QRE141J-153Y RESISTOR 15kØ,1/4W
R7038 QRE141J-393Y RESISTOR 39kØ,1/4W
R7040 QRE141J-103Y RESISTOR 10kØ,1/4W
R7041 QRE141J-122Y RESISTOR 1.2kØ,1/4W
R7042 QRE141J-182Y RESISTOR 1.8kØ,1/4W
R7051 QRE141J-331Y RESISTOR 330Ø,1/4W
R7052 QRE141J-331Y RESISTOR 330Ø,1/4W
R7053 QRE141J-331Y RESISTOR 330Ø,1/4W
R7054 QRE141J-331Y RESISTOR 330Ø,1/4W
