JVC SR-VS30E Service Manual

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-20
C511 NCB21HK-103X CAPACITOR 0.01µF,50V
C512 NCB21HK-103X CAPACITOR 0.01µF,50V
C513 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C514 NCB21HK-103X CAPACITOR 0.01µF,50V
C515 NCB21HK-103X CAPACITOR 0.01µF,50V
C516 NCB21HK-103X CAPACITOR 0.01µF,50V
C518 NCB21EK-104X CAPACITOR 0.1µF,25V
C519 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C520 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C535 NCB21HK-103X CAPACITOR 0.01µF,50V
C551 QEKJ1HM-105 E CAPACITOR 1µF,50V
C553 NCB21HK-103X CAPACITOR 0.01µF,50V
C554 QEKJ1HM-105 E CAPACITOR 1µF,50V
C556 NCB21HK-103X CAPACITOR 0.01µF,50V
C557 QEKJ1HM-105 E CAPACITOR 1µF,50V
C559 NCB21HK-103X CAPACITOR 0.01µF,50V
C560 QEKJ1HM-105 E CAPACITOR 1µF,50V
C561 QEKJ1HM-105 E CAPACITOR 1µF,50V
C563 NCB21HK-103X CAPACITOR 0.01µF,50V
C568 NDC21HJ-680X CAPACITOR 68pF,50V
C569 NDC21HJ-680X CAPACITOR 68pF,50V
C570 NDC21HJ-680X CAPACITOR 68pF,50V
C571 NDC21HJ-680X CAPACITOR 68pF,50V
C572 NDC21HJ-680X CAPACITOR 68pF,50V
C573 NDC21HJ-680X CAPACITOR 68pF,50V
C575 NDC21HJ-101X CAPACITOR 100pF,50V
C901 NCB21HK-331X CAPACITOR 330pF,50V
C902 NCB21HK-331X CAPACITOR 330pF,50V
C903 NCB21HK-471X CAPACITOR 470pF,50V
C905 NCB21HK-471X CAPACITOR 470pF,50V
C907 NCB21HK-471X CAPACITOR 470pF,50V
C908 NCB21HK-471X CAPACITOR 470pF,50V
C909 NCB21HK-331X CAPACITOR 330pF,50V
C910 NCB21HK-331X CAPACITOR 330pF,50V
C911 NCB21HK-471X CAPACITOR 470pF,50V
C912 NCB21HK-331X CAPACITOR 330pF,50V
C913 NCB21HK-471X CAPACITOR 470pF,50V
C914 NCB21HK-331X CAPACITOR 330pF,50V
C915 NCB21HK-471X CAPACITOR 470pF,50V
C916 NCB21HK-471X CAPACITOR 470pF,50V
C921 NCB21HK-331X CAPACITOR 330pF,50V
C922 NCB21HK-331X CAPACITOR 330pF,50V
C925 NCB21HK-103X CAPACITOR 0.01µF,50V
C926 NCB21HK-103X CAPACITOR 0.01µF,50V
C929 NCB21HK-102X CAPACITOR 0.001µF,50V
C930 NCB21HK-102X CAPACITOR 0.001µF,50V
C931 QEKJ1CM-107 E CAPACITOR 100µF,16V
C934 NCB21HK-223X CAPACITOR 0.022µF,50V
C935 NCB21HK-223X CAPACITOR 0.022µF,50V
C937 NCB21HK-223X CAPACITOR 0.022µF,50V
C938 NDC21HJ-330X CAPACITOR 33pF,50V
C939 NCB21EK-104X CAPACITOR 0.1µF,25V
C940 NCB21HK-223X CAPACITOR 0.022µF,50V
C942 NCB21HK-103X CAPACITOR 0.01µF,50V
C943 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C944 QEKJ1CM-106 E CAPACITOR 10µF,16V
C945 QEKJ1CM-106 E CAPACITOR 10µF,16V
C946 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C947 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C949 QEKJ0JM-227 E CAPACITOR 220µF,6.3V
C950 NCB21EK-104X CAPACITOR 0.1µF,25V
C951 QEKJ1CM-476 E CAPACITOR 47µF,16V
C952 NCB21HK-103X CAPACITOR 0.01µF,50V
C953 NCB21HK-103X CAPACITOR 0.01µF,50V
C954 QEKJ0JM-227 E CAPACITOR 220µF,6.3V
C955 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
L501 QQL29BJ-100Z COIL 10µH
L503 QQL29BJ-100Z COIL 10µH
L505 QUY153-050Y IM BUS WIRE
L901 QQL071J-4R7Y COIL 4.7µH
L902 QQL071J-4R7Y COIL 4.7µH
L903 QQL071J-4R7Y COIL 4.7µH
L904 QQL071J-4R7Y COIL 4.7µH
L905 QQL071J-1R0Y COIL 1.0µH
L906 QQL071J-4R7Y COIL 4.7µH
L907 QQL071J-4R7Y COIL 4.7µH
L908 QQL071J-4R7Y COIL 4.7µH
L909 QQL071J-4R7Y COIL 4.7µH
L910 QQL231J-R22Y COIL 0.22µH
L911 QQL071J-150Y COIL 15µH
L912 QQL071J-150Y COIL 15µH
L913 QUY153-050Y IM BUS WIRE
L916 QQL071J-1R0Y COIL 1.0µH
L919 QUY153-050Y IM BUS WIRE
OT1 QYTDSF3010Z SCREW,X4
OT2 QYTDSF3010Z SCREW,X4
ET1 LP30918-001A EARTH PLATE
ET2 LP30915-002A EARTH PLATE
! TB1 LP10414-001B TERMINAL BOARD
J901 PEMC1177 RGB21PIN SOCKET,AV2
J902 PEMC1177 RGB21PIN SOCKET,AV1
J903 QNN0023-003 PIN JACK,A.OUT(L)
J904 QNN0023-002 PIN JACK,A.OUT(R)
J905 PU60659 MINI JACK,SAT.CTL
J906 QND0084-001 S JACK,S OUT
CN502 QGF1208F1-15 FPC CONNECTOR,(1-15)VHS MAIN
CN503 QGB2024J1-09S CONNECTOR,(1-9)VHS MAIN
CN504 QGB2024J1-10S CONNECTOR,(1-10)VHS MAIN
CN505 QGB2024J1-12S CONNECTOR,(1-12)VHS MAIN
CN506 QGB2024J1-11S CONNECTOR,(1-11)VHS MAIN
CN901 QGF1208F1-09 FPC CONNECTOR,(1-9)VHS MAIN
CN902 QGB2024J1-09S CONNECTOR,(1-9)VHS MAIN
******************************
A/C HEAD BOARD ASSEMBLY <12>
PW1 LP10122-01A1 A/C HEAD BOARD ASSY
CN1 QGF1208F1-07 FPC CONNECTOR
******************************
DEMOD BOARD ASSEMBLY <14>
PW1 LPA10094-04A DEMOD BOARD ASSY
IC6701 MSP3417D IC
or MSP3417DG3 IC
or MSP3417G IC
Q6701 2SC3936/BC/-X TRANSISTOR
