Getting Started
Right front
speaker
Right rear
speaker
To center speaker
To left front speaker
To right front speaker
To left rear speakerTo right rear speaker
To subwoofer
Left front
speaker
Center speaker
Left rear
speaker
COMPACT
SUPER VIDEO
DIGITAL
SURROUND
DIGITAL•EX
PRO LOGIC
VOLUME
PHONES
DSPSURROUNDSOURCE
STANDBY
STANDBY/ON
DVD DIGITAL CINEMA SYSTEM TN-A35
Center unit
Subwoofer
Y
AC IN
SUBWOOFER
CENTER
SPEAKER
REAR
SPEAKERS
RIGHT LEFT
FRONT
SPEAKERS
RIGHT LEFT
CAUTION
SPEAKER IMPEDANCE 6-8 OHMS
Speaker Layout Diagram
EN01-09TH-A35[B].pm6 03.1.20, 11:25 AM6

JVC TH-A35 Specifications

Amplifier Section

power per channel	45 watts
impedance	6 ohms
frequency	1 kHz

Subwoofer

woofer size	16 cm
sustained power capacity	100 W
impedance	10 Ω

Audio Section

weight	4.8 kg
frequency range	25 Hz to 200 Hz
dimensions	202 mm × 330 mm × 341 mm

Video Section

dimensions	92 mm × 97.5 mm × 92 mm
weight	650 g
frequency range	90 Hz to 20 kHz

Tuner Section

FM tuning range	87.50 MHz – 108.00 MHz
AM tuning range	522 kHz – 1 629 kHz
power supply	230 V, 50 Hz
