AUX FUNCTION Screen (TK-C9300U/E, TK-C9301EG)
AUX FUNCTION
Sets the input/output signal of the AUX terminal.
[Setting values : IN:ALARM, IN:D/N, OUT:ALARM, OUT:B&W]
(Default value: IN:ALARM)
IN:ALARM : Displays image on the monitor when alarm signal is input from the
AUX terminal.
IN:D/N : Switches image to the color/black-and-white mode when alarm
signal is input from the AUX terminal.
OUT:ALARM : Outputs alarm signal to the AUX terminal when movements are
detected.
OUT:B&W : Outputs alarm signal to the AUX terminal when the image switches
to black-and-white.
Memo
When "IN:ALARM" is selected, press the [SET] button to display the sub-
menu. You can set the [TITLE SIZE], [TITLE COLOR], [TITLE COLOUR]
and [ALARM TIME] items on the sub-menu.
If D/N switch is OFF, "IN:D/N" can not be selected. If D/N switch is
changed to OFF during "IN:D/N" is displayed, "IN:D/N" is changed to
"OFF".
m
TITLE SIZE
Sets the size of the title displayed when alarm signal is input. When set to
"DOUBLE", the text displayed will be twice the size of the text in the menu.
[Setting values : NORMAL, DOUBLE] (Default value: DOUBLE)
m
TITLE COLOR (U model), TITLE COLOUR (E/EG model)
Sets the color of the title displayed when alarm signal is input.
[Setting values : WHITE, GREEN, CYAN, YELLOW] (Default value: WHITE)
m
ALARM TIME
Sets the time to display alarm on the screen when alarm signal is input.
[Setting values : 5s to 10s, 15s, 20s, 30s, 60s] (Default value: 5s)
IN POLARITY
Sets the polarity of the input alarm signal.
[Setting values : MAKE (short), BREAK (open) (Default value: MAKE)
ADVANCED MENU
13
