XV-SA600BK/XV-SA602SL
3-6
Item
Parts number Parts name Area
A
Parts list (DVD Traverse mechanism assembly)
Q'ty
Description
Block No. M2MM
1 LE20520-002A MECHA BASE 1
2 LE20516-001A SPINDLE BASE 1
3 QYSDST2605M TAPPING SCREW 3
4 LE30909-001A HOLDER 1
5 QAR0165-001 FEED MOTOR 1
6 LV41510-001A FEED GEAR 1
7 QYSPSPU2040M SCREW 2
8 LV41512-001A FEED GEAR 1
9 LV41517-003A LEAD SCREW 1
10 LV41511-002A FEED GEAR 1
11 LE40742-001A TORSION SPRING 1
12 QYSDSF2005Z SCREW 1
13 QYSDST2605M TAPPING SCREW 2
14 LE20517-001A HOLDER 1
15 LE40744-001A SPRING 1
16 LV41121-002A SLIDE SHAFT 2
17 QYSDST2605M TAPPING SCREW 1
18 QAL0342-001 OPTICAL PICK-UP 1
19 LE20519-001A ACTUATOR 1
20 LE30886-001A SPRING 1
21 QYSPSFU1740Z SCREW 2
22 LE30888-003A SPRING 1
23 QYSPSGU1430Z SCREW 1
24 LE40743-001A SPRING 1
25 LE40774-001A PLATE 1
26 QYSDST2606Z SCREW 1
27 QAL0284-001 F.P.C.WIRE ASSY 1
28 QAR0162-001 SPINDLE MOTOR 1
29 QYSPSPU1760Z SCREW 3
30 QYYASPF2608N SCREW 3
