Configuration and Operation
Operating Instructions for Powador -_EN Page
Non-grid feed mode
ok
Status message The display shows the corresponding
message.
Fault
!
Fault message The display shows the corresponding
message.
The red “Fault” LED is illuminated.
The inverter is not ready for grid feed, i.e.
no longer on the grid.
Fault
!
Fault message The display shows a SYM bus parameter
error.
.. Display
The display shows measured values and data and allows the con guration of the inverter. In normal operation, the
backlighting is switched o . As soon as you press one of the control buttons, the backlighting is activated. If no
button is pressed for a minute, it switches o again.
In sleep mode, the inverter deactivates the display regardless of the selected setting.
NOTE
Depending on the tolerances of the measuring elements, the measured and displayed values are not
always the actual values. However, the measuring elements ensure maximum solar yield. Due to
these tolerances, the daily yields shown on the display may deviate from the values on the grid
operator’s feed-in meter by up to %.
After being switched on and after the initial start-up is complete, the inverter displays the unit name.
Figure : Display (shows the unit name or menu item)
.. Control buttons
Operate the inverter with the two control buttons
Figure : Control buttons
Key
1 Shift button Opens menu
2 Set button Make settings or selection
Key
