2. Technical Data
2.1 Technical Data 230V Class
1) With the regulated systems F5-M as well as F5-S 5% must be subtracted as control reserve
2) This data is only valid for units with integrated PFC (see "unit identification")
3) The wire gauge is based on the maximum fuse rating, copper wire with minimum 75°C insulation rating, THHW or equivalent.
If branch circuit protection is selected based on rated input current, the wire size could be reduced.
4) This data is only valid for units with internal brake transistor GTR 7 (see "unit identification")
5) With units with integrated EMI filter the distance is less:
up to max. 5m line length and 4kHz operating frequency = Limit Value B (EN 55011)
up to max. 10m line length and 16kHz operating frequency = Limit Value A (EN 55022)
7) Rated operation means rated input voltage, rated output current, and rated carrier frequency.
8) 8 kHz only with a mounting plate > 55 in² and a 1.6 inch minimum distance to other components.
Inverter Size 05 07 09 10 12 13 14
Recommended Motor Power [hp] 1/2 1 2 3 5 7.5 10
Housing size A ABBDBDDEEG
Input Ratings
Supply voltage [V] 180...260 ±0 (230 V rated voltage)
Supply voltage frequency [Hz] 50 / 60 +/- 2
Input phases 1 1 311313131313 3 3 3
Rated input current [A] 4,0 4,0 2,8 8,0 8,0 5,6 14 9,5 14 9,5 19 13 19 13 21 29 36
Rated input current
2)
[A] – 3,2 – – 6,4 – – – – –
–
Rated input "real" power
2)
[kW] – 0.85 – – 1.5 – – – – –
–
Recommended maximum input fuse [A] 1515152015201525202520 25 35 50
Recommended wire gauge
3)
[awg] 1414141214121410121012 10 10
8
Output Ratings
Rated output power [kVA] 0,9 1.6 2.8 4.0 6.6 9.5 13
Rated motor power
[kW] 0.37 0.75 1,5 2,2 4.0 5.5
7.5
Rated output current [A] 2.0 4.0 6.8 9.6 15.2 22 28
Peak current (30 seconds)
1)
[A] 4,1 7.2 12,6 18 29.7 36
49.5
Over current fault (E.OC) trip level
[A] 5.0 8.6 15,1 21,6 35.6 43
59
Overload curve (see annex) 1
Output voltage
[V]
3 x 0...V input (3 x 0...255V
2)
)
Output frequency [Hz]
Generally 0 to 1600Hz (limited by control board and carrier frequency)
Rated switching frequency
[kHz]
8
8)
16 8 16 16 8 16 8 8
416
Maximum switching frequency [kHz] 8 16 8 16 16 16 16 16 16 16 16
Power loss at rated operation
7)
[W] 30 50 55 65 90 130 105 170 210 290
350 330
Power loss at rated operation
2)
[W] – 85 – – 130 – – – – –
–
Stall current at 4kHz [A] 2.3 4 7 10 10 16,5 24 33 33
Stall current at 8kHz
[A] 2.3 4 7 10 10 16,5 24
24 33
Stall current at 16kHz
[A] – 2.3 – 4 7 8 10 10 16,8
16,8 33
Braking Circuit
Min. braking resistance
4)
[Ohm] 100 56 100 56 47 33 27 16
16 13
Typ. braking resistance
4)
[Ohm] 180 100 100 68 56 47 22
22 16
Max. braking current [A] 4.5 7.5 4.5 7.5 9.5 12 15 25 25 29
Installation Information
30 100 30 330 330
330
30 65 30 165 330
330
– 30 – 65 130
330
Tightening torque for terminal strip [in lb] 4.5 11
Environmental
Max. heat sink temperature TOH [°C] 90°C / 194°F
Storage temperature [°C] -25...70 °C / -13…158°F
Operating temperature [°C] -10...45 °C / 14…113°F
Housing design / protection Chassis / IP20
Relative humidity max. 95% without condensation
Approvals
Tested in accordance with… EN 61800-3 /UL508C
Standards for emitted interference EN 55011 Class B / EN 55022 Class A
Standards for noise immunity IEC 1000-4-2 / -3 / -4 / -5/ -6
Climatic category 3K3 in accordance with EN 50178
Max. shielded motor cable length at 16kHz
5)
[ft]
B
14
15
Max. shielded motor cable length at 4 kHz
5)
[ft]
Max. shielded motor cable length at 8 kHz
5)
[ft]
