3.2.2 EMI (CE) - Filter
The KEBCO COMBIVERT frequency inverters are optionally available with EMI filters. Depending on
the housing size they are available from the factory already mounted to the inverter or as filter kits for
installation by the user. These filters allow the KEBCO COMBIVERT to meet the CE EMC directive 89/
339. All filters are dimensioned for the inverter's rated current and are designed to meet the conducted
emission limit as defined by EN55011/B. If the motor wires are shielded and longer than the maximum
values listed in the tables on pages 15-20, consult KEBCO for the proper filter. Also for a delta
connected line or for a low ground leakage filter solutions contact KEBCO.
The filter kits contain all required hardware for installation. Filters for sizes up to 200 hp include the
shielded supply wires which connect the filter to the inverter. Depending on the available space and filter
type, the filter can either be installed under the frequency inverter (sub-mounted), or beside the
frequency inverter (side mounted).
Accessories
EMI (CE) - Filter 230V-Class
For Inverter Phases Kit incl. Filter Filter Back mounting
size / housing
with housing
05,07 / A 1 internal option - -
07 / B 1 07.U5.B0B-1010 07.E5.T60-0061 B
09,10 / B 1 10.U5.B0B-1000 10.E5.T60-0001 B
09,10 / D 1 10.U5.B0D-1000 10.E5.T60-0002 D
07,09,10 / B 3 10.U5.B0B-2000 12.E5.T60-1001 B
09,10 / D 3 10.U5.B0D-2000 13.E5.T60-1001 D
12 / D 3 12.U5.B0D-2000 14.E5.T60-1001 D
13 / E 3 13.U5.B0E-2000 15.E4.T60-1001 E
14 / E 3 14.U5.B0E-2000 16.E5.T60-1001 E
14,15 / G 3 15.U5.B0G-2000 16.E4.T60-1001 G
15,16 / H 3 16.U5.B0H-2000 19.E4.T60-1001 H
17,18 / R 3 18.U5.B0R-2000 20.E4.T60-1001 R
19 / R 3 19.U5.B0R-2000 22.E4.T60-1001 R
20,21 / R 3 21.U5.B0R-2000 23.E4.T60-1001 side mount
EMI (CE) Filter 460V-Class
For Inverter Phases Kit incl. Filter Filter Back mount
Size / housing
with housing
07,09,10 / B 3 10.U5.B0B-3000 10.E5.T60-1001 B
07,09,10 / D 3 10.U5.B0D-3000 10.E5.T60-1002 D
12 / B 3 12.U5.B0B-3000 12.E5.T60-1001 B
12,13 / D 3 13.U5.B0D-3000 13.E5.T60-1001 D
14 / D 3 14.U5-B0D-3000 14.E5.T60-1001 D
12,13,14 / E 3 14.U5-B0E-3000 14.E4.T60-1001 E
15 / E 3 15.U5.B0E-3000 15.E4.T60-1001 E
16,17 / G 3 17.U5.B0G-3000 16.E4.T60-1001 G
18 / H 3 18.U5.B0H-3000 18.E4.T60-1001 H
19 / H 3 19.U5.B0H-3000 19.E4.T60-1001 H
20 / R 3 20.F5.x3R-xxxx 20.E4.T60-1001 internal mount
21,22,23 / R 3 2x.F5.x3R-xxxx 22.E4.T60-1001 internal mount
23 / U 3 23.U5.B0U-3000 23.E4.T60-1001 side mount
24,25 / U 3 25.U5.B0U-3000 25.F4-T60-1001 side mount
26,27 / U 3 27.U5.B0U-3000 27.E4-T60-1001 side mount
To Next Page
