KEB COMBIVERT F5 Series Instruction Manual

28
Accessories
3.1.2 Panel Mount Brake Resistors
Technical data braking resistor
1) Permissible power dissipation of the resistor is dependent on the duty cycle factor; braking time divided by 120 seconds.
The calculated peak braking time must be
< the load of the resistor.
Part number R
B
P
Rated
COMBIVERT Nominal power
1)
[W]
[OHM] [kW] 6 s 25 s 40 s
230 V - Class
07.BR.100-1180 180 44 05, 07 800 300 180
09.BR.100-1100 100 82 07, 09 1500 500 300
10.BR.100-1683 68 120 07, 09, 10, 13(E) 2200 800 500
12.BR.100-1333 33 250 10, 13(G) 4400 1300 750
13.BR.100-1273 27 300 13(G), 14 5400 1500 900
14.BR.100-1203 20 450 13(G), 14 7300 1800 1100
15.BR.110-1133 13 630 14, 15 10000 3200 1800
16.BR.110-1103 10 850 15, 16 14000 3600 2200
17.BR.110-1073 7 1100 15, 16, 17 21000 5400 3100
18.BR.110-1053* 5 1900 17,18 28000 7200 4400
19.BR.110-1356* 3.5 2200 19,20 42000 10800 6200
20.BR.110-1256* 2.5 3800 20,21 56000 14400 8800
*consult KEBCO for exact specifications
400 V - Class
07.BR.100-6620 620 56 05, 07 900 300 180
09.BR.100-6390 390 90 07, 09 1500 500 300
10.BR.100-6270 270 130 07, 09, 10 2100 800 500
12.BR.100-6150 150 230 12 3700 1300 750
13.BR.100-6110 110 350 12, 13 5000 1500 900
14.BR.100-6853 85 410 12, 13, 14 6500 1800 1100
15.BR.110-6563 56 620 12(E), 13(E,G), 14, 15 10000 3200 1800
16.BR.110-6423 42 820 13(G), 14(G), 15, 16 13500 3600 2200
17.BR.110-6303 30 1200 15(H), 16, 17 18500 5400 3100
18.BR.226-6203 20 1700 17(R), 18, 19 27500 7500 4500
19.BR.226-6153 15 2300 17(R), 18, 19, 20 37000 10000 6000
20.BR.226-6123 12 2900 18(R), 19(R), 20, 21 46000 12500 7500
21.BR.226-6103 10 3000 18(R), 19(R), 20, 21, 22 55000 15000 9000
22.BR.226-6866 8,6 4000 21(L), 22(L), 23 64000 17500 10000
23.BR.226-6676 6,7 5200 22(L), 23, 24(U) 82000 22000 12500
24.BR.226-6506 5 6900 23(U), 24(U), 25(U) 110000 30000 18000
25.BR.226-6436 4,3 8100 24(U), 25(U), 26(U), 27(U) 130000 35000 20000
26.BR.226-6386 3,8 9200 25, 26, 27(U) 145000 40000 22500
27.BR.226-6336 3,3 10000 25, 26, 27(U) 170000 45000 25000
28.BR.226-6226 2,2 15000 28(W), 29(W), 30(W) 250000 67000 37000
29.BR.226-6176 1,7 20000 28(W), 29(W), 30(W) 325000 90000 50000
30.BR.226-6136 1,3 26000 28(W), 29(W), 30(W) 425000 112000 62000
