KEB COMBIVERT F5 Series User Manual

4.2.4 Additional precharging resistor at master-slave operation
The external precharging resistor is required from housing size 29. The re-
sistor is used for additional energy input and limitation of the charging cur-
rent. The external resistor is switched into phase L1 at the precharge input
(=> „Circuit example for the master-slave operation with AIC/LCL lter and common mode
lter“).
Material number Resistance Rv Power Voltage
0090013-0048 5.8Ω 165 W 1100 V
4.3 Dimensions and weights
The COMBIVERT F5-AIC have identical housings with the COMBIVERT F5 drive con-
verters. Dimensions, weights and terminal descriptions can be found in the following
instruction manuals:
Size Housing Instruction manual
14 E Housing E
16 G Housing G
18 H Housing H
20, 22 R Housing R
24, 26, 27 U Housing U
28, 29, 30, 33, 34, 38 P Housing P
Table 13: Dimensions and weights
Theinstructionmanualscanbefoundinthespeciedlinksorunder
www.keb.de/de/service/downloads.
33
UNIT DATA

KEB COMBIVERT F5 Series Specifications

General

Control Method	Vector Control, V/f Control
Protection Class	IP20
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overtemperature
Communication Interfaces	CAN, PROFIBUS, Modbus RTU
Cooling Method	Fan Cooled
Relative Humidity	Up to 95% (non-condensing)
