BEARING- 13NOS
S.NO.
Code Qty. Description Location
1
6004
1
Output shaft—gearbox cover
Engine
2
6201
1
Middle shaft—gearbox cover
Engine
3
6301
1
Output shaft—gearbox cover
Engine
4
6203
1
Output shaft—left case
Engine
5
6202
1
Middle shaft—left case
Engine
6
6204
1
Output shaft—left case
Engine
7
TM-SCO7A87
1
Left crank—left case
Engine
8
TM-SCD5ASSCS12
1
Right crank—right case
Engine
8
K28x33x14
1
Crank pin—crank connecting big rod
Engine
9
K28x32x17
1
Clutch hub—cluch gear
Engine
10
6902NSE28 x15x7
1
Driven disc—output shaft
Engine
11
HK20 x29x18RS
1
Driven disc—output shaft
Engine
12
6002
2
Camshaft—atmolysis shaft fixing holer
Engine
PINSHAFT- 2NOS
S.NO.
Size (mm) Qty. Description Location
1 5Фx6 1
Super clutch
Engine
2 4Фx6.5 1
Oil pump
Engine
GASKET- 7NOS
S.NO.
Gasket Type Qty. Location
1
Cyliner head cover Rubber endurable against oil
1 Engine
2
Cylinder head Steel
1 Engine
3
Cylindr body
Asbestos rubber endurable
against oil
1 Engine
4
Crankcase Endurable oil asbestos rubber
1 Engine
5
Right crankcase cover Endurable oil asbestos rubber
1 Engine
6
Left crankcase cover Endurable oil asbestos rubber
1 Engine
7
Atmolysis chain adjuster
Endurable oil asbestos rubber
1 Engine
