MIXED GAS（
（（
（ARI AND FUEL）
））
）SYSTEM
MIXED GAS OIL ROAD：
：：
：
Fuel flows out of tank for its own weight and across inlet oil switch, at last goes into carburetor. In this process, fuel is filtrated
three times (first of all fuel is filtrated when it passes through netty nylon tupe before going into fuel filter, secondly fuel goes
through the cavity of fuel filter, finally fuel is filtrated when it passes through the filter installed between inlet oil switch and
carburetor).
Air cleaner is installed in the left side of motorcycle. Fuel and clean air are mixed into mixed fog gas, which is controlled by
inlet port and camshaft rocker arm, and then goes into combustion chamber.
Mixed gas forms and its flowing table
Gas fuel
Air fuel tank
Clean fuel filter
Filter cavity of fuel filter
Separate flame filter
Air cleaner joint port floater chamber
Foam tube
Throat tube
Combustion chamber
Air and fuel ratio：
：：
： Carburetor oil road
start： 7-8 ：1 maily including
idle speed： 10-12 ：1 1. Inlet oil road
slow speed： 12-14 ：1 2. Condensing oil road
common speed：15-17 ：1 3. Idle speed oil road
high speed： 13-15 ：1 4. Slow speed oil road
5. Common speed oil road
6. Great mixed gas road
