Keithley 2636 Reference Manual

Table 4-1
Source-measure capabilities
Model 2601/2602 Model 2611/2612 Model 2635/2636
Range Source Measure Range Source Measure Range Source Measure
100mV
1V
6V
40V
100nA
1µA
10µA
100µA
1mA
10mA
100mA
1A
3A
±101mV
±1.01V
±6.06V
±40.4V
±101nA
±1.01µA
±10.1µA
±101µA
±1.01mA
±10.1mA
±101mA
±1.01A
±3.03A
±102mV
±1.02V
±6.12V
±40.8V
±102nA
±1.02µA
±10.2µA
±102µA
±1.02mA
±10.2mA
±102mA
±1.02A
±3.06A
200mV
2V
20V
200V
1
100nA
1µA
10µA
100µA
1mA
10mA
100mA
1A
1.5A
10A
2
±202mV
±2.02V
±20.2V
±202V
±101nA
±1.01µA
±10.1µA
±101µA
±1.01mA
±10.1mA
±101mA
±1.01A
±1.515A
±10.1A
±204mV
±2.04V
±20.4V
±204V
±102nA
±1.02µA
±10.2µA
±102µA
±1.02mA
±10.2mA
±102mA
±1.02A
±1.53A
±10.2A
200mV
2V
20V
200V
3
100pA
1nA
10nA
100nA
1µA
10µA
100µA
1mA
10mA
100mA
1A
1.5A
+/-202mV
+/-2.02V
+/-20.2V
+/-202V
N/A
+/-1.01nA
+/-10.1nA
+/-101nA
±1.01µA
±10.1µA
±101µA
±1.01mA
±10.1mA
±101mA
±1.01A
±1.515A
+/-204mV
+/-2.04V
+/-20.4V
+/-204V
+/-102pA
+/-1.02nA
+/-10.2nA
+/-102nA
±1.02µA
±10.2µA
±102µA
±1.02mA
±10.2mA
±102mA
±1.02A
±1.53A
Max Power = 40.4W per channel Max Power = 30.603W per channel
1. 200V source range available only
when interlock is enabled. See
Section 10.
2. 10A range available only in pulse
mode.
Max Power = 30.603W per channel
3. 200V source range available only
when interlock is enabled. See
Section 10.
2600S-901-01 Rev. C / January 2008 Return to Section Topics 4-3
Series 2600 System SourceMeter® Instruments Reference Manual Section 4: Basic Operation
Compliance limit
When sourcing voltage, the SourceMeter can be set to limit current. Conversely, when sourcing
current, the SourceMeter can be set to limit voltage. The SourceMeter output will not exceed the
compliance limit. The maximum compliance limit is the same as the maximum values listed in
Table 4-2. Note that the compliance value will take the same sign as the source value, and the
maximum compliance limits are based on source range. See "Compliance limit" in Section 8 for
more information.
NOTE The only exception to the compliance limit not being exceeded is the
VLIMIT when operating as an ISOURCE. To avoid excessive (and
potentially destructive) currents from flowing, the VLIMIT will source
or sink up to 102mA for ISOURCE ranges on or below 100mA. For
the ranges 1A and above, the maximum current allowed is the
current source setting.
