2600S-901-01 Rev. C / January 2008 Return to Section Topics 13-35
Series 2600 System SourceMeter® Instruments Reference Manual Section 13: Factory Scripts
Flash firmware upgrade
As Keithley Instruments develops additional factory scripts, they will be made available on the
Keithley Instruments website (www.keithley.com) as a flash firmware upgrade for the Series 2600.
CAUTION External circuitry connected to input/output terminals while attempting a
flash upgrade may cause instrument and/or DUT damage. Disconnect
input/output terminals before performing a flash upgrade.
After downloading the new flash file from the Keithley Instruments website, use the Test Script
Builder (TSB) to upgrade the firmware of your Series 2600:
1. On the PC desktop, double-click the icon for the Test Script Builder.
2. On the Instrument Console toolbar, click the Open Instrument icon and then select your
communication interface from the Select Instrument Resource dialog box. Details on opening
communications are provided in Figure 2-8.
Figure 13-1
Pulse sweep example
Open Instrument icon
3. On the Instrument Console toolbar, click the Menu icon to display the menu.
Figure 13-2
Pulse sweep example
Menu icon
4. From the drop-down menu, select Instrument and then click Flash.
5. From the Select A Firmware Data File dialog box, use the browser to select the File name of
the new firmware and click Open to upgrade the firmware of the Series 2600.
