5-4 Return to Section Topics 2600S-901-01 Rev. C / January 2008
Section 5: Sweep Operation Series 2600 System SourceMeter® Instruments Reference Manual
Figure 5-2
Linear staircase sweep
Delay
Delay
Delay
Delay
X = Measurement
X
X
X
X
Measure
Measure Measure
Start
Step
Step
Step
Stop
Measure
Logarithmic staircase sweeps
This sweep is similar to the linear staircase sweep. The steps, however, are done on a logarithmic
scale as shown in the example sweep in
Figure 5-3. This example is a 5-point log sweep from 1V
to 10V. The sweep can be either positive-going or negative-going depending on relative start and
stop parameter values.
