Keithley 2636 Reference Manual

2600S-901-01 Rev. C / January 2008 Return to Section Topics 2-19
Series 2600 System SourceMeter® Instruments Reference Manual Section 2: TSP Programming
Figure 2-11
Renaming a project folder and/or script file
To change the name of a script file:
A) Right-click the script file, and click Rename
in the drop-down menu.
B) Type in the new name, making sure to include
the .tsp extension, and then press the Enter
key.
To change the name of a project folder:
A) Right-click the project folder, and click Rename
in the drop-down menu.
B) Type in the new name, and then press the Enter
key.
Script launch configuration
A script is to be loaded into the Series 2600 where it will be executed (run). The launch
configuration options include the following:
• Select which script files will be included in the launch.
• Set the launch order for the selected script files.
• Set the script launch to load-only, or to load-and-execute (run).
• Set script storage for the Series 2600: volatile or non-volatile. A script stored in volatile
memory will be lost when the SourceMeter power is turned off. A script stored in non-volatile
memory will not be lost after power is turned off.
When a script project is created, the launch is configured initially as follows:
• Only the first script file (“main”) is selected to be included in the launch.
• The launch type is set to load-and-execute (run).
• The script project is set to be stored in the volatile memory of the Series 2600. The script
will be lost when the Series 2600 power is turned off.
NOTE If the initial launch configuration meets your requirements, the script
is ready to be launched and is explained in “
Launching a script” later
in this section.
The flowchart in Figure 2-12 shows the basic process to change the launch configuration for a
script. The labels (A through G) are used to identify reference links which follow the illustration.
Figure 2-12
Changing a launch configuration
Start
Test Script
Builder
Open a
Resource
Select
Communications
Interface
Load-Only or
Load-and-Run
Select
TSP
Application
Select
Launch
Type
Select
Series 2600
Storage
Volatile or
Non-Volatile
Select Scipt Files
Set Launch
Sequence
Script
Project
AB D
Launch Configuration
EFG
Open Run
Dialog Box
C
Ready To
Launch
