Table 10-4 lists the command sequence for the diode programming example.
Custom sweep commands
Table 10-5 summarizes remote commands used for custom sweep operation. See
Section 18, “Configure list,” for more details on these commands.
Table 10-4
Staircase sweep programming example (diode test)
Command Description
*RST
:SENS:FUNC:CONC OFF
:SOUR:FUNC CURR
:SENS:FUNC ‘VOLT:DC’
:SENS:VOLT:PROT 1
:SOUR:CURR:START 1E-3
:SOUR:CURR:STOP 10E-3
:SOUR:CURR:STEP 1E-3
:SOUR:CURR:MODE SWE
:SOUR:SWE:RANG AUTO
:SOUR:SWE:SPAC LIN
:TRIG:COUN 10
:SOUR:DEL 0.1
:OUTP ON
:READ?
Restore GPIB default conditions.
Turn off concurrent functions.
Current source function.
Volts sense function.
1V voltage compliance.
1mA start current.
10mA stop current.
1mA step current.
Select current sweep mode.
1
Auto source ranging.
Select linear staircase sweep.
Trigger count = # sweep points.
2
100ms source delay.
Turn on source output.
Trigger sweep, request data.
1. This command should normally be sent after START, STOP, and STEP to avoid delays
caused by rebuilding sweep when each command is sent.
2. For single sweep, trigger count should equal number of points in sweep: Points = (Stop-
Start)/Step + 1. You can use SOUR:SWE:POIN? query to read the number of points.
Table 10-5
Custom sweep commands
Command Description
:SOURce:CURRent:MODE LIST
:SOURce:VOLTage:MODE LIST
:SOURce:LIST:CURRent <list>
:SOURce:LIST:CURRent:APPend <list>
:SOURce:LIST:CURRent:POINts?
:SOURce:LIST:VOLTage < list>
:SOURce:LIST:VOLTage:APPend <list>
:SOURce:LIST:VOLTage:POINts?
:SOURce:SWEep:RANGing <name>
Select current list (custom) sweep mode.
Select voltage list (custom) sweep mode.
Define I-source (list = I1, I2,… In).
Add I-source list value(s) (list =I1, I2,…In).
Query length of I-source list.
Define V-source list (list = V1, V2,… Vn).
Add V-source list value(s) (list =V1, V2,…Vn).
Query length of V-source list.
Select source ranging (name = BEST, AUTO, or FIXed).
