English
7
Installing the Microphone Unit
(DDX418/DDX4048BT only)
1 Check the installation position of the
microphone (accessory 7).
2 Remove oil and other dirt from the
installation surface.
3 Install the microphone.
4 Wire the microphone cable up to the unit
with it secured at several positions using
tape or the like.
⁄
• Install the microphone as far as possible from the
cell-phone.
Fix a cable with a commercial item of tape.
Peel the release coated paper of double-face
adhesive tape to fix on the place shown above.
Adjust the direction of the microphone to the driver.
Accessory 7
Removing the Unit
1 Remove the escutcheon by referring to
the removal procedure in the section
<Removing the Escutcheon>.
2 Insert the two removal tools 6 deeply into
the slots on each side, as shown.
Accessory 6
3 Lower the removal tool toward the
bottom, and pull out the unit halfway
while pressing towards the inside.
⁄
• Be careful to avoid injury from the catch pins on
the removal tool.
4 Pull the unit all the way out with your
hands, being careful not to drop it.
To Next Page
