Kenwood DNX7190DABS User Manual

Troubleshooting
103English
Troubleshooting
Problems and Solutions
If any trouble occurs, first check the following
table for possible problems.
NOTE
• Some functions of this unit may be disabled by
some settings made on this unit.
• What might seem to be a malfunction in your
unit may just be the result of slight misoperation
or miswiring.
Ñ About settings
• Cannot set up the subwoofer.
• Cannot set up subwoofer phase.
• No output from the subwoofer.
• Cannot set up the low pass filter.
• Cannot set up the high pass filter.
Subwoofer is not set to on.
 Set the subwoofer to on. See Speaker / X’over
setup (P.82).
The dual zone function is enabled.
 Set the dual zone function to off. See Zone Control
(P.86).
• Cannot select the output destination of the
subsource in the dual zone.
• Cannot adjust the volume of the rear speakers.
The dual zone function is disabled.
 Set the dual zone function to on. See Zone Control
(P.86).
• Cannot set up the equalizer.
• Cannot set up the crossover network.
The dual zone function is enabled.
 Set the dual zone function to off. See Zone Control
(P.86).
Ñ About audio operations
Radio reception is poor.
The car antenna is not extended.
 Pull out the antenna all the way.
The antenna control wire is not connected.
 Connect the wire correctly. See Connecting the
system and external components (P.99).
Cannot select a folder.
The random play function is enabled.
 Turn off the random function.
Cannot perform repeat play during VCD playback.
The PBC function is enabled.
 Turn off the PBC function.
The specified disc does not play, but another one
plays instead.
The disc is quite dirty.
 Clean the disc. See Precautions on handling discs
(P.4).
The disc is severely scratched.
 Try another disc instead.
The sound skips when an audio file is being
played.
The disc is scratched or dirty.
 Clean the disc. See Precautions on handling discs
(P.4).
The recording condition is bad.
 Record the file again or use another disc.
Ñ Others
The Touch Sensor Tone doesn’t sound.
The preout jack is being used.
 The Touch Sensor Tone cannot be output from the
preout jack.
Error Messages
When you fail to operate the unit correctly, the
cause of the failure appears as the message on
the screen.
There is an error in the speaker wiring. Please
check the connections.
Protective circuit has been activated because a speaker
cord has shorted or it has come in contact with the car
chassis.
 Wire or insulate the speaker cord as appropriate and
turn the power off and on again.
Hot Error
When the internal temperature of this unit rises to 60°C
or more, the protection circuit is activated and you may
not be able to operate the unit.
 Use the unit again after reducing the temperature
of the unit.
Mecha Error
The disc player is malfunctioning.
 Eject the disc and try inserting it again. Contact the
KENWOOD dealer if this indicator continues blinking
or the disc cannot be ejected.
Disc Error
An unplayable disc is inserted.
 Change the disc. See Playable Media and Files
(P.105).
Autogoods “130”
130.com.ua

Kenwood DNX7190DABS Specifications

General

Display diagonal	6.95 \
Display resolution	800 x 480 pixels
Built-in camera	No
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	BMP, JPEG, PNG
Video formats supported	H.264, MKV, MPEG1, MPEG2, MPEG4, WMV
Equalizer bands quantity	13
Text-to-speech message reader	-
Map storage	Memory card
Map coverage	Northern Europe, Southern Europe
Map view options	2D/3D
Lifetime map updates	Roads change, but with Lifetime Map Updates your map will always be up to date. Start fresh every few months by downloading a new edition of the industry's most accurate map. New editions are issued four times per year.
License term in years	3 year(s)
Bluetooth version	5.0
Bluetooth functions	Audiostreaming, Handsfree calling
DIN size	2 DIN
Form factor	Fixed
Product color	Black
Languages support	Multi
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, DAB+, FM, LW, MW
Preset stations quantity	20
Composite video in	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	2
Compatible memory cards	SD, SDHC, SDIO
Maximum memory card size	2000 GB
GPS accuracy - position	2 m
GPS accuracy - velocity	0.05 m/s
Cables included	USB
Power source type	DC

Weight and Dimensions

Depth	163 mm
Width	182 mm
Height	112 mm
Weight	2500 g
