Kenwood DNX7190DABS User Manual

Other External Components
72
Use Dashboard Camera
(Except DNR3190BTS)
A Dashboard Camera, DRV-N520 (optional
accessory), connected to this unit lets you play
video-recorded data and so on.
For details, see the instruction manual of
the Dashboard Camera DRV-N520 (optional
accessory).
NOTE
• To connect a dashboard camera, see P.102.
• To use the dashboard camera function, it is
necessary to set “Camera Assignment Settings” to
“Dashboard Camera”. (P.70)
Ñ Display the dashboard camera
screen
1
Press the [MENU]/[ ] button.
 Popup menu appears.
2
Touch [Camera].
123
1
Switching the View Camera
Touch to display the camera switching keys.
It is necessary to set “Camera Assignment
Settings” beforehand. See To switch the view
camera (P.69).
2
Camera off
Touch to exit the camera screen.
3
Key display
Touch to display the dashboard camera
control keys.
Ñ Added function
Display the map while playing the
recorded file
1
Play the recorded file.
See the instruction manual of the
Dashboard Camera.
2
Touch [ ].
Return to the recorded file playback
screen
1
Touch [ ].
External audio/video players
(AV-IN)
1
Connect an external component to the
AV-IN input terminal. (P.99)
2
Select [AV-IN] as the source. (P.16)
3
Turn on the connected component and
start playing the source.
NOTE
• To select the AV-IN source, it is necessary to set
"AV-IN" to "None" in [Camera Assignment
Settings]. (P.70)
Autogoods “130”
130.com.ua

Kenwood DNX7190DABS Specifications

General

Display diagonal	6.95 \
Display resolution	800 x 480 pixels
Built-in camera	No
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	BMP, JPEG, PNG
Video formats supported	H.264, MKV, MPEG1, MPEG2, MPEG4, WMV
Equalizer bands quantity	13
Text-to-speech message reader	-
Map storage	Memory card
Map coverage	Northern Europe, Southern Europe
Map view options	2D/3D
Lifetime map updates	Roads change, but with Lifetime Map Updates your map will always be up to date. Start fresh every few months by downloading a new edition of the industry's most accurate map. New editions are issued four times per year.
License term in years	3 year(s)
Bluetooth version	5.0
Bluetooth functions	Audiostreaming, Handsfree calling
DIN size	2 DIN
Form factor	Fixed
Product color	Black
Languages support	Multi
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, DAB+, FM, LW, MW
Preset stations quantity	20
Composite video in	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	2
Compatible memory cards	SD, SDHC, SDIO
Maximum memory card size	2000 GB
GPS accuracy - position	2 m
GPS accuracy - velocity	0.05 m/s
Cables included	USB
Power source type	DC

Weight and Dimensions

Depth	163 mm
Width	182 mm
Height	112 mm
Weight	2500 g
