KERN ALJ User Manual

TALJG_A/TALSG_A/TPLJG_A/TPLSG_A-BA-e-2011 83
Tolerance check start
 To use the scale container, tare the scale.
 Place the weighed material. The tolerance check will start.
Weighed material
below
the preset tolerance
Weighed material
in the preset
tolerance range
Weighed material
above
the preset tolerance

After the optional printer is connected, the indication value can be printed by
pressing the PRINT button.
Sample printouts (KERN YKB-01N):
Weighed material
below
the preset tolerance
Weighed material
in the preset
tolerance range
Weighed material
above
the preset tolerance
23-08-20 9:36:43 AM
23-08-20 9:36:43 AM
23-08-20 9:36:43 AM
Lim. 1:
9.000 g
Lim. 1:
9.000 g
Lim. 1:
9.000 g
Lim. 2:
11.000 g
Lim. 2:
11.000 g
Lim. 2:
11.000 g
Gewic.:
8.900 g
Gewic.:
10.000 g
Gewic. :
11.700 g
TEST : KO! ---
TEST : OK!
TEST : KO! +++
Return to the weighing mode
 Press the ON/OFF button.
