15 Interfaces
The balance can communicate with external peripherals using the interface. Data can
be sent to a printer, PC or control displays. In the same way, control commands and
data inputs may occur via the connected devices (such as PC, keyboard, barcode
reader).
15.1 RS-232C interface
The balance is equipped as per standard with an RS232C interface to connect a pe-
ripheral device (e.g. printer or computer).
15.1.1 Technical data
Connection
9 pin d-subminiature bushing
Baud rate
1200/2400/4800/9600/19200 optional
Parity
Empty / Odd number / Even number
15.1.2 Interface cable
Balance
9-poles
PC
9-poles
Balance
9-poles
Printer
9-poles
