Maintenance
847
Fuses
Relay
Refer to the following table for the
relay type.
SENSOR4 10 A
[All] A/Con Relay, Cooling Fan Motor
[Smartstream D2.2] Oil Level Sensor, Stop Lamp Switch, Electronic
Thermo Valve
[Smartstream G2.5] Variable Intake Solenoid Valve, Purge Control
Solenoid Valve, Oil Control Valve (Intake/Exhaust)
[Smartstream G3.5] Variable Intake Solenoid Valve, Purge Control
Solenoid Valve, Variable Oil Pump Solenoid, Oil Control Vavle #1/#2/
#3/#4
SENSOR7 15 A
[Smartstream D2.2] Engine Room Junction Block (PTC Heater #1
Relay), PTC (Positive Temperature Coefficient) Breather, Oil Pump
Valve, Electronic VGT (Variable Geometry Turbocharger) Actuator,
EGR Cooling Bypass Solenoid Valve
[Smartstream G2.5] Injector #1/#2/#3/#4, IBU (Integrated Body
Control Unit), ECM (Engine Control Module)
[Smartstream G3.5] Injector #1/#2/#3/#4/#5/#6
ECU1 15 A ECM (Engine Control Module)/PCM (Power train Control Module)
ABS4 7.5 A ESP (Electronic Stability Program) Control Module
POWER
OUTLET2
20 A Rear Console Power Outlet
POWER
OUTLET1
20 A Luggage Power Outlet
Fuse Name Symbol Fuse r Ating Circuit Protected
S4
S7
E1
4
POWER
OUTLET
2
POWER
OUTLET
1
Relay Name Symbol TYPE
DCU Relay MICRO
Start Relay MICRO
Fuel Pump Relay MICRO
Fuel Filter Heating
Relay
MICRO
PTC Heater #1 Relay MICRO
B/Alarm Horn Relay MICRO
PTC Heater #2 Relay MICRO
Blower Relay MICRO
Rear Heated Relay MINI
DCU
FUEL
PUMP
PTC
HEATER
1
PTC
HEATER
2
