KP310V1.0 Controller Operation Manual
- 21 -
8.2 Programmable output list
8.2.1 Remote set
Terminal “8” has “Remote” function; the function is only valid in “Remote mode”.
No. Contents Note
1 0—Remote start normally
open
2
1—Remote start normally
closed
3
2—Remote Stop normally
open
4
3—Remote Stop normally
closed
5
4—Remote start & stop
normally open
6
5—Remote start & stop
normally closed
Normally Open ： in the default state, input signal
open （ high potential）；
input signal close （ low potential） is valid；
Normally Closed ： in the default state, input
signal close （ low potential）；
input signal open （ high potential） is valid；
8.2.1.1 Remote start normally open
In the “Remote mode ”, after Terminal “8” is closed （ low potential）, genset start after Remote
start delay（parameters can be setup）.Terminal “8” open （ high potential）, genset won’t stop.
8.2.1.2 Remote start normally closed
In the “Remote mode ”,after Terminal “8” is open （ high potential）,genset start after remote start
delay（parameters can be setup）.Terminal “8” close （ low potential）, genset won’t stop.
8.2.1.3 Remote Stop normally open
In the “Remote mode ”,After Terminal “8” is closed （ low potential）, genset won’t start.Terminal
“8” open （ high potential）,genset stop after Remote Stop Delay（parameters can be setup）.
8.2.1.4 Remote Stop normally closed
In the “Remote mode ”,After Terminal “8” is open （ high potential）, genset won’t start.Terminal
“8” close （ low potential）,genset stop after Remote Stop Delay（parameters can be setup）.
