DRAIN REQUIREMENTS
■ A new drain hose is supplied with your dishwasher. If drain
hose is not long enough, use a new drain hose with a
maximum length of 12 ft (3.7 m) that meets all current AHAM/
IAPMO test standards, is resistant to heat and detergent, and
ts the 1" (2.5 cm) drain connector of the dishwasher.
NOTE: Do not connect multiple drain hoses together.
■ Make sure to connect drain hose to waste tee or disposer
inlet above drain trap in house plumbing and 20" (50.8 cm)
minimum above the oor. It is recommended that the drain
hose either be looped up and securely fastened to the
underside of the counter or be connected to an air gap.
■ Make sure to use an air gap if the drain hose is connected to
house plumbing lower than 20" (50.8 cm) above suboor or
oor.
Use of air gap
■ If required, the air gap should be installed in accordance with
the air gap installation instructions. When you are connecting
the air gap, a rubber hose (not provided) will be needed to
connect to the waste tee or disposer inlet.
■ Use 1/2" (1.3 cm) minimum I.D. drain line ttings.
WATER SUPPLY REQUIREMENTS
■ This dishwasher has a water heating feature and also requires
a connection to a hot water supply line.
■ A hot water line with 20 psi to 120 psi (138 kPa to 862 kPa)
water pressure can be veried by a licensed plumber.
■ 120°F (49°C) water at dishwasher.
■ 3/8" (0.95 cm) O.D. copper tubing with compression tting or
exible braided water supply line.
NOTE: 1/2" (1.3 cm) minimum plastic tubing is not
recommended.
■ A 90° elbow with 3/4" (0.95 cm) hose connection with rubber
washer.
■ Do not solder within 6" (15.2 cm) of the water inlet valve.
■ If installed in new construction, make sure the house water
supply lines have been ushed prior to connecting the
dishwasher to remove any debris that may exist in the supply
line.
NOTE: If replacing an existing dishwasher, it is recommended
to install a new water line and drain hose (supplied) with the
new dishwasher.
ELECTRICAL REQUIREMENTS
Be sure that the electrical connection and wire size are adequate
and in conformance with the National Electrical Code,
ANSI/NFPA 70 - latest edition, and all local codes and
ordinances.
A copy of the above code standards can be obtained from:
National Fire Protection Association
1 Batterymarch Park
Quincy, MA 02169-7471
You Must Have:
■ 120 V, 60 Hz, AC only, 15 A or 20 A, fused electrical supply
■ Copper wire only
■ A maximum of 2 eld wiring supply conductors (12 AWG
largest size) plus 1 grounding conductor are permitted in the
terminal box.
We Recommend:
■ A time-delay fuse or circuit breaker.
Circuit Requirements:
■ The dishwasher may be installed on the same circuit as a
garbage disposal providing that the branch circuit cannot
exceed rated circuit load and must comply with all governing
codes and regulations such as but not limited to National
Electrical Code, ANSI/NFPA 70 - latest edition.
■ No electrical connections other than the dishwasher power
and ground connections can be made inside of the dishwasher
terminal box.
If connecting dishwasher with a power supply cord:
■ Use UL Listed power cord kit marked for use with
dishwasher.
■ Plug into a grounded 3 prong outlet. Outlet must
meet all local codes and ordinances.
If connecting dishwasher with direct wiring:
■ Use exible, armored, or nonmetallic sheathed
copper wire with grounding wire that meets the wiring
requirements for your home and local codes and
ordinances.
■ Use a UL Listed/CSA Approved metallic
strain relief.
Air gap
To Next Page
