14
5. Built-up oors – add shims as needed
Note: The wood runners that come with the shipping base work
well for shims.
Built-up oors: If the kitchen oor is higher than the cabinet
opening’s oor - for example, the kitchen oor tile does not
extend into the cabinet opening - add shims, as needed, in the
area shown to bring cabinet oor up to same level as the kitchen
oor.
NOTE: Shims must be securely attached to oor to avoid
movement when the dishwasher is in use.
Cut insulation blanket along perforation for cabinet opening
height of 33
5
/8" (85.4 cm). For other cabinet opening heights, do
not cut the insulation blanket.
ELECTRICAL CONNECTION
– For Direct Wire, begin with Step 7
– For Power Cord, wait until Step 18
If installing with direct wire, route the cable as shown. Do not
connect the wire to the product at this time. This connection will
be made later, after the unit is installed into the cabinet opening.
Route cable from power supply through cabinet hole. (Cable
must extend to the right front side of cabinet opening.) Tape
cable to the oor in area shown. This will prohibit cable from
moving when dishwasher is moved into cabinet opening.
6. If installing into a 33
5
/8" (85.4 cm)
opening
6”
(15.2 cm)
7. Direct wire – route cable
Shim

KitchenAid KDFM404KPS Specifications

General

Style	built-in dishwashers
Color	stainless steel
Load Capacity	16
Number of Cycles	5
Cycle Selections	express wash, normal, prowash, rinse, tough
Options/Settings	extended heat dry, 4 hour delay, heated dry, hi temp wash, sani rinse
Drying Type	heated drying
Noise level	44 decibels adjusted
Control Type	touchpad
Delay Start	yes
Load Sensor	yes
Number of Racks	3
Cycle Signal	yes
Water Filter	yes
Food Disposer	no
Sanitize Settings	yes
Annual Energy Consumption	270 kilowatt hours
Voltage	120 volts
Current	15 amperes

Weight and Dimensions

Depth	24 1/2 inches
Height	33 5/8 inches
Width	23 7/8 inches
Net Weight	105 pounds
