KitchenAid KDFM404KPS User Manual

16
Measure the height of cabinet opening from the underside of the
countertop to the oor where the dishwasher will be installed.
Be sure to measure the lowest point on the underside of the
countertop and the highest point on the oor.
Use wrench to initially loosen leveling legs if needed.
Adjust all four leveling legs to the same height by rotating each
foot clockwise or counterclockwise as needed.
The unit comes with the legs set for a 33
5
/8" (85.4 cm) height
installation. If your opening height is 34½" (87.6 cm), you would
therefore need to raise all four legs by 7/8" (2.22 cm).
NOTE: Adjust rear leg height rst before moving unit into the cut
out.
Legs can be removed if necessary for tight installations.
CONNECT WATER LINE TO FILL VALVE
– For Copper line, begin with Step 12
– For Flexible line, begin with Step 14
If using copper tubing, measure overall length of copper tubing
required to reach the water supply, cut to length, and attach with
compression ttings.
11. Measure cabinet opening
Leveling leg adjustment
12. Copper Water Line

KitchenAid KDFM404KPS Specifications

General

Style	built-in dishwashers
Color	stainless steel
Load Capacity	16
Number of Cycles	5
Cycle Selections	express wash, normal, prowash, rinse, tough
Options/Settings	extended heat dry, 4 hour delay, heated dry, hi temp wash, sani rinse
Drying Type	heated drying
Noise level	44 decibels adjusted
Control Type	touchpad
Delay Start	yes
Load Sensor	yes
Number of Racks	3
Cycle Signal	yes
Water Filter	yes
Food Disposer	no
Sanitize Settings	yes
Annual Energy Consumption	270 kilowatt hours
Voltage	120 volts
Current	15 amperes

Weight and Dimensions

Depth	24 1/2 inches
Height	33 5/8 inches
Width	23 7/8 inches
Net Weight	105 pounds
