ERROR CODES
ERROR CODES / BLINKING LIGHTS
Issue
Code Shown
(7 Seg Display)
(if present)
Code Shown on
Front Panel LED *
(# blinks, Pause, #
blinks)
What will happen? What to do?
Dishwasher fails
to operate ll valve
correctly
F1E1
1 Pause 1 Pause -
pause, repeat
Drain sequence
will begin, machine
operation will be
prevented
Turn off water to unit (if possible).Turn
off power to unit. If the water cannot
be turned off, DO NOT turn off power
and keep door closed. Press Cancel
key one time to silence alarm tone. Call
service.
Motor controller
failure
F1E2
1 Pause 2 Pause,
repeat
Cycle ends Call service
No water present at
dishwasher
H2O
8 Pause 1 Pause -
pause, repeat
Cycle is paused
Ensure ll hose is connected to
product. Ensure water supply is turned
ON. Press Start to resume cycle. If
alarm still present, call service.
Wash motor failure F7E1/F7E2
7 Pause 1 Pause,
repeat/7 Pause 2
Pause, repeat
Cycle ends Call service
Dishwasher
overlls
F8E4
8 Pause 4 Pause -
pause, repeat
Drain sequence
will begin, machine
operation will be
prevented
For Professional Installers
Turn off water to unit (if possible). Turn
off power to unit. If the water cannot
be turned off, DO NOT turn off power
and keep door closed. Press Cancel
key one time to silence alarm tone. Call
service.
For Self Installers
■ Press CANCEL button twice or cycle
power. This may clear the issue.
■ Check to see if the wire connector is
connected to the oat switch on the
drip tray. See step 46. If the wire is
off, reconnect and then hit the cancel
button twice.
■ Check to see if there is any water in
the drip tray. If water is in the drip
tray, remove the water and reinstall
the drip tray. Make sure to connect
the wiring to the oat. Step 46.
Check to see where water may have
leaked into the drip tray. (Check the
water inlet ttings in steps 15 and 16
to see if they are leaking)
■ If water was in the tray and no leaks
were found, run the product on the
shortest installation cycle while
checking for leaks. The access panel
should be off to observe any leaks.
■ If problem still exists, call for service.
Fill valve stuck on F8E5
8 Pause 5 Pause -
pause, repeat
Drain sequence
will begin, machine
operation will be
prevented
Turn off water to unit (if possible).Turn
off power to unit. If the water cannot
be turned off, DO NOT turn off power
and keep door closed. Press Cancel
key one time to silence alarm tone. Call
service.
Dishwasher will not
drain
F9E1
9 Pause 1 Pause -
pause, repeat
Cycle ends
If drain hose is connected to a garbage
disposal, conrm that drain hose is not
clogged and disposal plug has been
knocked out. If unit still will not drain,
call service.
Water present
under dishwasher
FAE5
10 Pause 5 Pause -
pause, repeat
Cycle ends Call service.
User interface
service
communication
fault
F6E1
6 Pause 1 Pause -
pause, repeat
Product will not able to
start or resume cycles
Call service.

KitchenAid KDFM404KPS Specifications

General

Style	built-in dishwashers
Color	stainless steel
Load Capacity	16
Number of Cycles	5
Cycle Selections	express wash, normal, prowash, rinse, tough
Options/Settings	extended heat dry, 4 hour delay, heated dry, hi temp wash, sani rinse
Drying Type	heated drying
Noise level	44 decibels adjusted
Control Type	touchpad
Delay Start	yes
Load Sensor	yes
Number of Racks	3
Cycle Signal	yes
Water Filter	yes
Food Disposer	no
Sanitize Settings	yes
Annual Energy Consumption	270 kilowatt hours
Voltage	120 volts
Current	15 amperes

Weight and Dimensions

Depth	24 1/2 inches
Height	33 5/8 inches
Width	23 7/8 inches
Net Weight	105 pounds
