TP-5592 7/961-10 Specifications
Engine Specifications—3-Phase Models (Continued)
14CCOZ/
11.5CCFOZ
20CCOZ/
17.5CCFOZ
24CCOZ
20CCFOZ
Flex Plate to Rotor Bolt Torque
—ft. lbs. (Nm)
30 (41)
Cylinder Head Torque—ft. lbs. (Nm)
Initial ft. lbs (Nm) 29 (39)
Final ft. lbs (Nm) (2-step
intervals)
58 (79)
Flex Plate to Flywheel Bolt Torque
—ft. lbs. (Nm)
20 (27)
Generator Adapter Plate to
Flywheel Housing Bolt Torque
—ft. lbs. (Nm)
30 (41)
Overbolt Torque—ft. lbs. (Nm) 30 (41)
Inlet Water Line Hose I.D.—in.
(mm) (seawater pump inlet)
1.0 (25)
Outlet Water Line Hose I.D.
—in. (mm) (mixing elbow outlet)
3 (76)
Fuel Inlet—(fuel pump inlet) 3/8 ID—1/4 NPT
Fuel Return Size—Type 3/8 ID—1/4 NPT
Controller
The generator set has a relay controller with hourmeter.
For a description of the controller, see Section
2—Operation.
Controller Features
D Electric starting with a start/stop switch located on
the controller or by (optional) remote start
D Rubber mounted to minimize vibration
D Safety shutdowns for overheating, low oil
pressure, and overspeed (optional)
D Starter interlock to prevent reengagement of
starter whenever engine is running
D Controller connections by plugs/receptacles and
clearly identified corrosion-resistant terminals to
eliminate the possibility of misconnection
D Quick disconnect on 22-pin wiring harness
D External 6-pin connector for remote panel harness
D Hourmeter for scheduling maintenance
D Voltage/frequency adjustable PowerBoostä
voltage regulator
