Appendix E. Controller Displays from the Engine ECM
The controller display showing engine information is dependent upon the engine manufacturer and the corresponding Engine
Control Module (ECM). The following list indicates which engine displays are available by the engine manufacturer. This
information is subject to change by the engine manufacturer.
Note:
See the generator set specification sheet for engine model identification.
Some engines do not have an ECM and in some cases the ECM information is not available as a controller display. In these
situations, critical information like oil pressure and coolant temperature are displayed by the controller using independent engine
sensors not used by the ECM.
Controller Displays
as Provided by the
Engine ECM
Engine Manufacturer (and model)
Kohler Diesel
(KDI M, TM*)
Kohler
Diesel
(KDI TCR)
Kohler Gas
(KG2204,
KG2204T)
Kohler Gas
(KG6208,
KG6208T,
KG10V08,
KG10V08T)
GM and
PSI/Doosan
DD/MTU
John
Deere
Volvo
Intake air pressure
S/D
D
Intake air
Temperature
D
D
D
S/D
D
D
Coolant level
D
D
D
D
D
D
Coolant temperature
D
C/S/D
C/S/D
C/S/D
C/S/D
C/S/D
C/S/D
Crankcase pressure
D
ECM battery voltage
S
S/D
S
S
S
Engine model
number
S
S
S
S
S
S
S
Engine serial number
S
S
S
S
S
S
S
Engine speed
C/S/D
C/S/D
C/S/D
C/S/D
C/S/D
C/S/D
C/S/D
C/S/D
Fuel pressure
D
C/S/D
C/S/D
C/S
C/S†
C/S/D
Fuel rate
S
S
S
S
S
Fuel temperature
D
S
S/D
S
Oil level
S†
S†
S/D†
S†
S†
Oil pressure
C/S/D
D
C/S/D
C/S/D
C/S/D
C/S/D
C/S/D
Oil temperature
S
D
SD
C = Value displayed on controller, S = Value displayed in Site Tech, D = ECU diagnostic is supported
* Electronic governor and ECM are optional on KDI M and TM engines.
† Controller uses local analog input to obtain this information
Note:
REOZMD/ROZMC (Mitsubishi engines) have an ECM but do not send signals to the generator set controller.
