TP-6694 6/22 63
2.7.2 Overview
Displays basic and commonly sought after information about the generator set. This information scrolls automatically after about
5 minutes of no user input (pushbutton/rotary selector dial or button activity).
To change from auto scrolling to fixed display, press the rotary dial and the main menu will appear. Press the rotary dial again
to select the first menu item Overview. Turn the rotary dial to select the desired fixed view.
Note:
Some displays are engine dependent; refer to the Appendix titled: Controller Displays from the Engine ECM.
Overview (Auto Scrolling Display)
Overview - - >
##.# hr
Active Shutdowns (if present)
Active Warnings (if present)
GenSet State ######
Avg V L- L:
#.# V
Frequency:
#.# Hz
Current:
#.# A
Average kW
#### kW
Coolnt Temp:
### F
Oil Pressure:
# PSI
Fuel Level:
#%
Fuel Pressure:
## PSI
Battery:
##.# V
Eng Runtime:
##.# h
CHG1: ##.#V
##.# A
CHG2: ##.#V
##.# A
SW Version:
1.02)
Diesel Powered Models
(requires fuel tank
sensor) - - >
Engine Dependent (see
NOTE above) - - >
With 10 Amp Charger
GM87448 Only
(N/A if no charger) - >
