Kohler Command Pro CH245 Service Manual

1.11
Section 1
Safety and General Information
1
515.54
[20.297]
299.68
[11.799]
387.22
[15.245]
Ø1
STRAIGHT
PTO
305.66
[12.034 ]
317.22
[12.489]
404.76
[15.936]
195.50
[7.697]
105.00
[4.134]
4X 45°
4X 3/8-16 UNC 2B INCH
18 MM FULL THREAD
127.00
[5.000]
Ø
283.47
[11.160]
165.10
[6.500]
Ø
2X 30°
55.80
[2.197]
METRIC FLANGE:
6X M8 X 1.25-6H TAP 18 MIN.
SAE B FLANGE:
6X 5/16-24 UNF 2B INCH 18 MIN.
70.00
[2.756]
278.16
[10.951]
35.00
[1.378]
133.50
[5.256]
103.00
[4.055]
APPROXIMATE
CENTER OF
GRAVITY
176.82
[6.962]
106.82
[4.206]
73.82
[2.906]
17.00
[0.669]
2X Ø 11.00 X 28.00 SLOT
[0.433] X [11.02]
C
L
CYLINDER
2X Ø 11.25
[0.443]
40.00
[1.575]
APPROXIMATE
CENTER OF
GRAVITY
39.70
[1.563]
Dimensions in millimeters.
Inch equivalents shown in ( ).
Figure 1-10. Typical Engine Dimensions-CH440 With Low-Profi le Air Cleaner.
