31. MAINTENANCE
4-21
n CHECK OIL LEVEL IN TORQFLOW TRANSMISSION, ADD OIL AS NECESSARY
1. Remove the floor plate and check oil with dipstick.
2. If oil level is low, remove the dipstick and add oil through the
oil filler port.
3. After filling with oil, check the oil level. Do not overfill.
Always use genuine Komatsu Forklift or DEXRON II Automatic
Transmission Fluid.
TORQFLOW Trans Case Capacity
TORQFLOW
transmission (including
torque converter)
12.5 qts (11.8 L)
(2.6 UK gal)
Watch out for HOT OIL. Immediately after operations, the oil will be very hot.
Wait for the oil temperature to go down before starting this maintenance operation.
To Next Page
