32. REPLACEMENT PROCEDURES
4-33
32.3 REPLACING LAMPS
Check for any blown fuses or disconnections in the wiring harnesses,
and replace the lamps as necessary.
Lamp capacity
Head lamp 55 W (For 12 Volt)
Turn signal lamp 23 W (For 12 Volt)
Driving lamp 8 W (For 12 Volt)
Tail lamp 8 W (For 12 Volt)
Stop lamp 23 W (For 12 Volt)
Back-up lamp 3 W (For 12 Volt)
Warning lamp 2.0 W (For 12 Volt)
Meter lighting lamp 3.4 W (For 12 Volt)
