OPERATION 10. HANDLING RADIO CONTROL
3-17
10.1 FLOW CHART FOR STARTING, OPERATING USING RADIO
CONTROL
Set selector switch to RADIO CONTROL.
Turn key on machine to ON position.
Set fuel control dial on machine to MIN position.
Buzzer on machine sounds for approx. 3 seconds
Lights and all rotating lamps light up for approx. 2 seconds
Red rotating lamp stays lighted up.
Set parking lever to FREE position (raised).
Turn transmitter power switch ON (turn key switch
on right side of transmitter one stage).
Transmitter pilot lamp lights up, transmitter buzzer
sounds twice.
Red rotating lamp on machine goes out.
Turn transmitter power switch OFF.
Replace transmitter battery with charged battery.
(It takes several seconds for red rotating lamp to go
out)
Is transmitter pilot lamp lighted up?
Press engine starting switch, start engine.
Set control lever to neutral.
Turn engine speed switch to IDLING position.
Does engine start?
Turn transmitter key switch to 2nd stage for
approx. 1 sec.
Yellow rotating lamp lights up and it becomes possible
to operate machine.
NO
YES
YES
NO
If the battery voltage has gone down, the engine may
not start even when it is cranked with the starting motor.
In such a case, charge or replace the battery.
If this operation is not carried out, lever operations
will be invalid. Switch operations (horn, etc.) are valid
To Next Page
