Komatsu PC360LC-11 Service Manual

F
G
H
E
D
C
A
B
KS000346
Track shoe (mm)
PC360LC-11 (17m Long Reach)
Operating weight (kg)
Ground pressure (kg/cm
2
)
700mm 42127 0.64
800mm 42507 0.56
850mm 42697 0.54
Working Range Unit PC360LC-11 (17m Long Reach)
Max Digging Reach (to bucket teeth) mm 17000
NOTICE
Specifications are subject to change without notice.
Unit
PC360LC-11 (17m Long Reach)
A Maximum digging height mm 14595
B Maximum dumping height mm 11490
C Maximum digging depth mm 12300
D Maximum wall digging depth mm 9445
E Maximum digging depth for 2400mm level mm 12200
F Minimum digging reach mm 17000
G Maximum reach at ground level mm 16880
H Minimum swing radius mm 5970
I Maximum height of minimum swing mm 11700
17M LONG REACH BOOM AND ARM ATTACHMENTS AND OPTIONS
6-26

Komatsu PC360LC-11 Specifications

General

Brand	Komatsu
Model	PC360LC-11
Category	Excavators
Language	English
