ARM/PIN INFORMATION
A
A
B
B
KS000370
2
4
1
3
A - A
B - B
PC490/LC-11
1 370 mm
+0.2
-0.7
3 370 mm
+1.0
-0.0
2 100 mm
-0.036
-0.090
4 100 mm
-0.036
-0.090
ATTACHMENTS AND OPTIONS ARM/PIN INFORMATION
6-33
