2-STAGE LOW IDLING PILOT LAMP
The 2-stage low
idling pilot lamp lights up when the 2-stage low
idling is effective.
At a place of high altitude and such, the 2-stage low idling be-
comes effective automatically, and the pilot lamp lights up.
The pilot lamp lights up when the 2-stage low idling is set to
ON as well.
When the 2-stage low idling becomes effective, the display
pops up.
REMOTE POSITIONER DISPLAY
The remote positioner display lights up in green when the re-
mote positioner is effective.
When the remote positioner function is changed from OFF to
ON, the display pops up.
(A): When only RAISE operation is effective
(B): When only LOWER operation is effective
(C): When RAISE and LOWER operations are effective
POWER MODE DISPLAY
The power mode display indicates the set state of the power
mode.
By selecting the mode with the power mode selector switch
and with the monitor, one of the following lamps lights up.
(A): Power mode
(B): Economy mode
(C): E light mode
When the mode is changed, the display pops up.
SHIFT HOLD PILOT LAMP
The shift hold pilot lamp lights up when the shift hold function
works.
OPERATION EXPLANATION OF COMPONENTS
3-35
